Leadshine 2 Phase Motor Unipolar 311.52(2.2)nm 86hs35+m542 2 Phase Stepper Drive

US $190.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Leadshine 2 phase motor unipolar 311.52(2.2)NM 86HS35+M542 2 phase stepper Drive 24-50DCV 1.0-4.2A M542 Introductions: The M542 V2.0 is a high performance microstepping drive based on pure-sinusoidal current control technology. Owing to the above technology and the self-adjustment technology (self-adjust current control parameters) according to different motors, the driven motors can run with smaller noise, lower heating, smoother movement and have better performances at higher speed than most of the drives in the markets. It is suitable for driving 2-phase and 4-phase hybrid stepping motors. Features: *Extremely cost-effective *Good high speed performance *Supply voltage up to +50 VDC *Output current up to 4.2A *Self-adjustment technology *Pure-sinusoidal current control technology *Pulse input frequency up to 300 KHz *TTL compatible and optically isolated input *Automatic idle-current reduction *15 selectable resolutions in decimal and binary, up to 25,600 steps/rev *Suitable for 2-phase and 4-phase motors *Support PUL/DIR and CW/CCW modes *Short-voltage, over-voltage, over-current protections Specifications: Parameters M542 Min Typical Max Unit Output current 1.0 - 4.2 (3.0 RMS) A Supply voltage +20 +36 +50 VDC Logic signal current 7 10 16 mA Pulse input frequency 0 - 300 kHz Isolation resistance 500 M? Applications: Suitable for a wide range of stepping motors, from NEMA size 17 to 34. It can be used in various kinds of machines, such as X-Y tables, engraving machines, labeling machines, laser cutters, pick-place devices, and so on. Particularly adapt to the applications desired with low noise, low heating, high speed and high precision. 86HS35 Features: *2-phase hybrid step motor *High torque design *Standard NEMA 34 dimensions *Series or parallel and unipolar wiring *Optimized for microstepping Specifications: General Step Angle 1.8° Step Angle Accuracy +5%(full step, no load) Temperature Rise 80°CMax Ambient Temperature -10°C -- +50°C Insulation Resistance 100M?min.500VDC Dielectric Strength 500VAC for one minute Shaft Radial Play 0.06 Max.(450g-load) Shaft Axial Play 0.08 max.(450g-load) Number of Leads 8 Electric Model Number Connection Holding Torque Oz-in (Nm) Phase Current (Amps) Phase Resistance (Ohm) Phase Inductance (mH) Rotor Inertia Oz-in-sec2 (g*cm2) 86HS35 Bipolar (Parallel) 495.6(3.5) 4.0 0.7±10% 3.9±20% 0.0142(1000) Bipolar (Series) 495.6(3.5) 2.0 2.8±10% 15.6±20% Unipolar 311.52(2.2) 2.8 1.4±10% 3.9±20% Matching drives: Model Match drives 86HS35 EM705/EM806/DM870/DM1182 86HS45 86HS85 EM705/EM806/DM870/DM1182/ DM2282 Applications: Suitable for all kinds of small automation equipment and instruments, such as: pneumatic marking machine, marking machine, cutting machine, laser marking machine, plotter, small engraving machine, CNC machine tools, handling equipment, etc. The efficiency is very high for the users who expect low vibration, little noise, high precision and high speed small equipments. Other stepper sets available in FASTTOBUY: M860 + 86HS35 Leadshine 2-phase Stepper Set (Drive + Motor) M860 + 86HS35 3.5N.m New M860 + 86HS45 Leadshine 2-phase Stepper Set (Drive + Motor) M860 + 86HS45 4.5N.m New M860 + 86HS85 Leadshine 2-phase Stepper Set (Drive + Motor) M860 + 86HS85 8.5N.m New M860 + 86HS120 Leadshine 2-phase Stepper Set (Drive + Motor) M860 + 86HS120 12N.m New We accept Paypal only. Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com TradeManager: fasttobuy skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM We only use the DHL, FEDEX, UPS and EMS to ship the orders. Fast To Buy Ltd decide to choose the suitable express service for the orders . Fast To Buy Ltd is not responsible on the custom tax for any order. Customer should pay for the custom fee in any case. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: If you want to return the item, please contact us in 14 days first and make sure the package is un-opened. The buyer has to pay for the go and back delivery cost and the custom fee of each country. Fast To Buy Ltd will make refund for the part in 24 hours after receiving it. This returns policy does not affect your statutory rights. Fast To Buy Ltd won't take any responsibilities if customers provide wrong shipping infomation such as address, code or phone number etc. Kindly note: Pls check and confirm the part NO. and your application before place order, we can accept return or refund within 14 days for the quality reason only, thank you.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Leadshine
MPN	86HS35+M542
Model	86HS35+M542
