Leadshine 2phase Stepper Set (drive+motor) Dm442 + 57hs13 1.3n.m Nema23 For Cnc

US $145.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Leadshine 2-phase Stepper Set (Drive + Motor) DM442 + 57HS13 1.3N.m New DM442 Features: *Anti-Resonance, provides optimum torque and nulls mid-range instability *Motor self-test and parameter auto-setup technology, offers optimum responses with different motors *Multi-Stepping allows a low resolution step input to produce a higher microstep output for smooth system performance *Microstep resolutions programmable, from full-step to 102,400 steps/rev *Supply voltage up to +40 VDC *Output current programmable, from 0.5A to 4.2A *Pulse input frequency up to 200KHz *TTL compatible and optically isolated input *Automatic idle-current reduction(Reduction rate can be software configured) *Support PUL/DIR and CW/CCW modes *Over-voltage, over-current, phase-error protections Specifications: Parameters DM442 Min Typical Max Unit Output current 0.5 - 4.2 (3 RMS) A Supply voltage +20 - +40 VDC Logic signal current 7 10 16 mA Pulse input frequency 0 - 200 kHz Isolation resistance 500 M? Applications: Sutible for applications require high performance, extra low motro noise, extra smooth movement stepper systems, such as CNC routers, small and medium size milling or engraving machines, laser machines, lab automation instruments, textile equipment, medical devices, assembly machines, pick-and-place devices, etc. 57HS13 Features: *2-phase hybrid step motor *High torque design *Standard NEMA 23 dimensions *Series or parallel and unipolar wiring *Optimized for microstepping Specifications: General Step Angle 1.8° Step Angle Accuracy +5%(full step, no load) Temperature Rise 80°CMax Ambient Temperature -10°C -- +50°C Insulation Resistance 100M?min.500VDC Dielectric Strength 500VAC for one minute Shaft Radial Play 0.06 Max.(450g-load) Shaft Axial Play 0.08 max.(450g-load) Number of Leads 8 Electric Model Number Connection Holding Torque Oz-in (Nm) Phase Current (Amps) Phase Resistance (Ohm) Phase Inductance (mH) Rotor Inertia Oz-in-sec2 (g.cm2) 57HS13 (Bipolar) Parallel 254.88(1.8) 4.0 0.5±10% 2.1±20% 0.006532(460) (Bipolar) Series 254.88(1.8) 2.0 2.0±10% 8.4±20% Unipolar 184.08(1.3) 2.8 1.0±10% 2.1±20% Matching drives: Model Match drives 57HS04 EM503/EM705/DM556 57HS09 57HS13 57HS22 Applications: Suitable for all kinds of small automation equipment and instruments, such as: pneumatic marking machine, marking machine, cutting machine, laser marking machine, plotter, small engraving machine, CNC machine tools, handling equipment, etc. The efficiency is very high for the users who expect low vibration, little noise, high precision and high speed small equipments. Other stepper sets available in FASTTOBUY: DM442 + 42HS08 Leadshine 2-phase Stepper Set (Drive + Motor) DM442 + 42HS08 0.8N.m New DM442 + 57HS09 Leadshine 2-phase Stepper Set (Drive + Motor) DM442 + 57HS09 0.9N.m New DM442 + 57HS13 Leadshine 2-phase Stepper Set (Drive + Motor) DM442 + 57HS13 6.35N.m New DM442 + 57HS22 Leadshine 2-phase Stepper Set (Drive + Motor) DM442 + 57HS22 2.2N.m New We accept Paypal only. Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com TradeManager: fasttobuy skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM We only use the DHL, FEDEX, UPS and EMS to ship the orders. Fast To Buy Ltd decide to choose the suitable express service for the orders . Fast To Buy Ltd is not responsible on the custom tax for any order. Customer should pay for the custom fee in any case. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: If you want to return the item, please contact us in 14 days first and make sure the package is un-opened. The buyer has to pay for the go and back delivery cost and the custom fee of each country. Fast To Buy Ltd will make refund for the part in 24 hours after receiving it. This returns policy does not affect your statutory rights. Fast To Buy Ltd won't take any responsibilities if customers provide wrong shipping infomation such as address, code or phone number etc. Kindly note: Pls check and confirm the part NO. and your application before place order, we can accept return or refund within 14 days for the quality reason only, thank you.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Leadshine
MPN	DM442 + 57HS13
Model	DM442 + 57HS13
Country of Manufacture	China
