Leadshine Updated Servo Kit Hbs507+573hbm20-1000 (replace 573s20-ec-1000+hbs57)

US $253.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Leadshine Updated Servo Kit HBS507+573HBM20-1000 (replace 573S20-EC-1000+HBS57) New Features Closed-loop, eliminates loss of synchronization Broader operating range – higher torque and higher speed Reduced motor heating and more efficient Smooth motion and super-low motor noise Do not need a high torque margin No Tuning and always stable Fast response, no delay and almost no settle time High torque at starting and low speed, high stiffness at standstill Lower cost Introduction The HBS series offers an alternative for applications requiring high performance and high reliability when the servo was the only choice, while it remains cost-effective. The system includes a 3-phase stepper motor combined with a fully digital, high performance drive and an internal encoder which is used to close the position, velocity and current loops in real time, just like servo systems. It combines the best of servo and stepper motor technologies, and delivers unique capabilities and enhancements over both, while at a fraction of the cost of a servo system. Specifications Electrical Specifications (Tj = 25oC/77oF) Parameters HBS57 Min Typical Max Unit Output current 0 - 8.0 (Peak) A Input voltage 20 36 50 VDC Logic signal current 7 10 16 mA Pulse input frequency 0 - 200 kHz Isolation resistance 500 M? Control Signal Connector - Screw Terminal Pin Name I/O Description 1 PUL+ I Pulse signal: In single pulse (pulse/direction) mode, this input represents pulse signal, each rising or falling edge active (software configurable, see hybrid servo software operational manual for more detail); In double pulse mode (software configurable), this input represents clockwise (CW) pulse, active both at high level and low level. 4-5V when PUL-HIGH, 0-0.5V when PUL-LOW. For reliable response, pulse width should be longer than 10?s. Series connect resistors for current-limiting when +12V or +24V used. The same as DIR and ENA signal. 2 PUL- I 3 DIR+ I Direction Signal: In single-pulse mode, this signal has low/high voltage levels, representing two directions of motor rotation. In double-pulse mode (software configurable), this signal is counter-clock (CCW) pulse, active both at high level and low level. For reliable motion response, DIR signal should be ahead of PUL signal by 5?s at least. 4-5V when DIR-HIGH, 0-0.5V when DIR-LOW. Please note that rotation direction is also related to motor-driver wiring match. Exchanging the connection of two wires for a coil to the driver will reverse motion direction. The direction signal’s polarity is software configurable. 4 DIR- I 5 ENA+ I Enable signal: This signal is used for enabling/disabling the driver. In default, high level (NPN control signal) for enabling the driver and low level for disabling the driver. Usually leftUNCONNECTED (ENABLED). Please note that PNP and Differential control signals are on the contrary, namely Low level for enabling. The active level of ENA signal is software configurable. 6 ENA- I 7 ALM+ O Alarm Signal: OC output signal, active when one of the following protection is activated: over-voltage, over current, short circuit and position following error. This port can sink or source 20mAcurrent at 24V. In default, the resistance between ALM+ and ALM- is low impedance in normal operation and become high when HBS57 goes into error. The active level of alarm signal is software configurable. See Hybrid servo software operational manual for more detail. 8 ALM- O Encoder Feedback Connector – DSub15 Female Pin Name I/O Description 1 EA+ I Encoder channel A+ input 2 EB+ I Encoder channel B+ input 3 EGD GND Signal ground 4 HW I Reserved 5 HU I Reserved 6 FG GND Ground terminal for shielded 7 EZ+ I Reserved 8 EZ- I Reserved 9 HV I Reserved 10 NC - Not Connected 11 EA- I Encoder channel A- input 12 EB- I Encoder channel B- input 13 VCC O +5V @ 100 mA max. 14 NC - Not Connected 15 NC - Not Connected Power and Motor Connector- Screw Terminal Pin Name I/O Description 1 U O Motor Phase U 2 V O Motor Phase V- 3 W O Motor Phase W 4 +Vdc I Power Supply Input (Positive) 20-45VDC recommended, leaving rooms for voltage fluctuation and back-EMF. 5 GND GND Power Ground (Negative) 573HBM20-1000 is the Upgraded version of 573S20EC-1000 http://www.leadshine.com/Product_Show.aspx?ID=181 Specification: Step angle 1.2° Position accuracy 1.2°± 0.06° Number of phase 3 Temp rise(Max.) 80 Celsius Dielectric strength 500VDC Insulation resistance 100 MOhm(500VDC) Radial play Max.0.025mm(Load 450g) Axial play Max.0.075mm(Load 920g) Insulation class B Holding torque 2.0 Nm Inertia 500 g.cm2 Weight 1.4 kg Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM Shipment: Once payment received. Item will be shipped out within 1-3 working days by DHL, Fedex, UPS, EMS ASAP. Usually it takes 3-7 working days to most of the country. You will be notified the traking number once shipped out. Kindly please note the Tax fee and Customs clearance fee are not included in the item’s listing price. Kindly please feel free to contact us before shipping if there’s any thing we can do for you. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: We accept return or refund within 14 days for the quality reason, not man-made reason. Kindly please contact us before returning the package. Payment will be refunded to you within 24hrs once the package received by us. You understanding appreciate. Kindly note: Pls check and confirm the part NO. and your application before place order, any further assistance please feel free to let us know.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Leadshine
MPN	HBS507+573HBM20-1000
Model	HBS507+573HBM20-1000
