Leeson 1-1/2 Hp 3450 Rpm 56 Frame 115/208-230v 5/8" Shaft Tefc #110094 C6c34fb6h

US $225.00

Pearland, Texas, United States
Jan 29th

Open on mobile:
QR code

NEW UNUSED LEESON MOTOR FOR SALE...ELECTRIC MOTOR...SEE DESCRIPTION BELOW MAKE MODEL HORSE POWER RPM VOLTAGE PHASE LEESON 110094.00 1.5 HP 3450 115 208-230 VAC SINGLE Product Features List Price :$ 637 Catalog No 110094.00 Model C6C34FB6J Product type AC MOTOR Stock Stock Description 1.5HP..3450RPM.56.TEFC.115/208-230V.1PH.60HZ.CONT.NOT.40C.1SF.RIGID.GENERAL PURPOSE.C6C34FB6J Information shown is for current motor's design Engineering Data Volts 115 Volts 208-230 Volts F.L. Amps 17 F.L. Amps 8.5 F.L. Amps S. F Amps None S. F Amps S. F Amps RPM 3600 Hertz 60 HP 1.5 Duty CONTINUOUS TYPE CF KW 1.12 Frame 56 Serv. Factor 1.0 Phase 1 Max Amb 40 Design L Code H Insul Class B Protection NOT Therm.Prot. Eff 100% 72 Eff 75% PF 80 UL Yes CSA Yes Bearing OPE 6203 CC Number CE No Bearing PE 6203 Load Type Inverter Type Speed Range NONE Motor Wt. 34 LB Enclosure TEFC Lubrication POLYREX EM Nameplate 993500 Mounting RIGID Rotation SELECTIVE CCW Assembly Shaft Dia. 5/8 IN Ext. Diag. Cust Part No Outline Ext. Diag2 Packaging B Outline Dash No Winding C632212 Carton Label Leeson Gen Purpose GROUP: 3 Iris Paint STANDARD Test Card 01 Form Factor RMS Amps Const Torque Speed Range Torque Peak AB Code Peak@DegC Resistance Connection Rework Status Rework TYPE Hazardous Loc NONE Brake Motors Explosion Proof Temp Op Code FORCE Class GROUP: VDC Class GROUP: ADC Brake Coil OHMs @25 C Performance Torque UOM LB-FT Inertia (WK?) .06 LB-FT^2 Torque 2.25(Full Load) 5.6(Break Down) 5.3(Pull Up) 5.5(Locked Rotor) CURRENT (amps) 8.5(Full Load) 0(Break Down) 0(Pull Up) 46(Locked Rotor) Efficiency (%) 0(Full Load) 70.5(75% Load) 66.1(50% Load) 52.9(25% Load) PowerFactor (Full Load) 73.5(75% Load) 62.7(50% Load) 46(25% Load) Load Curve Data @60 Hz, 230 Volts, 1.5 Horsepower Load Amps KW RPM Torque EFF PF Rise By Resis Frame Rise 0.0 4.67 0.259 3598 0.0 0.0 24.1 0.0 - 0.25 5.07 0.536 3561 0.56 52.9 46.0 0.0 - 0.5 5.89 0.85 3530 1.12 66.1 62.7 0.0 - 0.75 7.05 1.191 3496 1.69 70.5 73.5 0.0 - 1.0 8.45 1.555 3454 2.28 72.0 80.0 82.0 - 1.25 9.52 1.813 3424 2.65 71.1 82.8 0.0 - 1.5 10.33 2.0 3399 2.9 70.0 84.2 0.0 - The approximate shipping weight is 35 lbs.*** All items are sold "as is". Unless described as "new" above, items are used.

Condition:	New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...	Brand	LEESON
Model	C6C34FB6H
