Lenel Lnl-1320 Dual Interface Reader Controller

US $350.00

Los Angeles, California, United States
Feb 21st

Open on mobile:
QR code

This auction is for 1 Lenel Systems International LNL-1320 Series II RoHS Dual Reader Interface Module , brand new (board has been powered up & functions 100%), in original factory anti-static bubble wrap. ? Supports clock and data or Wiegand Data1 and Data0 reader communications ? Over 75 different readers approved for use ? Up to eight different card formats ? Supports the issue codes for magnetic and Wiegand formats ? Door Strike output ? Red status LEDs ? RS-485 two-wire or four-wire interface ? Elevator control for six floors The LNL-1320 Dual Reader Interface (DRI) Module attaches to specific card reader devices. The interface is the communications link between the Intelligent System Controller (ISC) and the card reader. The LNL-1320 DRI is compatible with personal identification number (PIN) keypads or access control card readers. It also works with the access control card readers that include PIN keypads with either standard Wiegand Data1 and Data0 or clock and data reader communications. Functions Alarm Inputs and Alarm Outputs - Four different inputs per reader. A set of dedicated inputs are used for REX, normally-open and normally-closed door status. Two auxiliary inputs can be configured as NO, NC, supervised or unsupervised. Two additional unsupervised inputs supply the status for cabinet tamper and power failure. There are three Form C relay outputs per reader. One output is a dedicated strike output and the other two outputs are software configurable. Elevator Control - Restricts or allows the ability to access specific floors. Up to six floors and one cab reader can be controlled with one LNL-1320 DRI Module . Certifications and Approvals UL Standards UL294, Access Control System Units Approvals Installation/Configuration Notes & Connection Considerations RS-485: 4000 ft (1200 m) maximum • Two-wire communication is Belden 9842 or equivalent • Four-wire communication is Belden 9843 or equivalent • Plenum cabling is Belden 88102 or equivalent Technical Specifications Alarm Inputs and Outputs Cabinet Tamper Monitor: One unsupervised, dedicated EOL Resistors: 2 x 1 k? resistor per supervised input Power Failure Monitor: One unsupervised, dedicated Alarm Outputs: Four auxiliary Form C outputs (two per reader) rated at 5 A; 30 VDC resistive Board Dimensions: 8 in. x 6 in. x 1 in. (20 cm x 15 cm x 2.5 cm) Weight: 16 oz (0.5 kg) Indicators Two status LEDs Communications Port 1: RS-485 (two-wire or four-wire) 2400 to 38400 bps async Connections Inputs: Twisted pair, 30 ? maximum Power: Twisted pair, 18 AWG (1.2 mm) RS-485: Twisted pair(s) with shield 24 AWG (1.2 mm) minimum Environmental Considerations Relative Humidity: 0% to 95%, non-condensing Temperature (Operating): +32°F to +158°F (0°C to +70°C) Temperature (Storage): -67°F to +185°F (-55°C to +85°C) Power Requirements Backup Battery: 3 V Lithium, type BR2325 Input (AC): 12 VAC ± 15%, 600 mA RMS Input (DC): 12 or 24 VDC ± 15%, 450 mA Reader Output: Regulated Mode, 80 mA per reader **************NOTE: FREE SHIPPING TO CONTINENTAL US ONLY. WILL NOT SHIP OVERSEAS. HAWAII EXCLUDED**************** Posted with eBay Mobile

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	LENEL
MPN	LNL-1320
