Leviton 23-13-b Locking Wiring Connector 20a 125v L5-20r (black)

US $17.00

  • Feasterville-Trevose, Pennsylvania, United States
  • Mar 7th
Open on mobile:
QR code
LEVITON 23-13-B Locking Wiring CONNECTOR 20A 125V L5-20R Locking Connector (Black) NEW STOCK#: 2313-B AC Horsepower Ratings Horsepower Rating: 1 HP Electrical Specifications Grounding: Grounding Amperage: 20 Amp Voltage: 125 Volt NEMA: L5-20R Pole: 2 Wire: 3 Dielectric Voltage: Withstands 2000V per UL498 Current Interrupting: Certified for current interrupting at full rated current Temperature Rise: Max 30C after 250 cycles OL at 200 percent rated current Environmental Specifications Flammability: Rated HB or better UL94 Operating Temperature: -40C to 60C Mechanical Specifications Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral Terminal Accom.: 18-10 AWG Product ID: Ratings are permanently marked on device Cord Range: .385 - .780 Wire Gauge: 16-10 AWG Product Features NEMA: L5-20R Color: Black Standards and Certifications NEMA: WD-6 ANSI: C-73 UL498: File E13393 UL Fed Spec WC-596: File E13393 CSA C22.2 No. 42: File LR-406 NOM: 057 _____________________________________ T-_SHELF_6/6/2014
Condition:
New other (see details): A new, unused item with absolutely no signs of wear. The item may be missing the original packaging, or in the original packaging but not sealed. The item may be a factory second or a new, unused item with defects. See the seller’s listing for full details and description of any imperfections. ...
Brand leviton
Country/Region of Manufacture United States
Model 2313-B
