Leviton Gftr1-w Self-test Tamper Resist. Gfci Outlet W Wallplate Smartlockpro

US $61

Brooklyn, New York, United States
Jun 9th

Open on mobile:
QR code

Brand Features Peace of mind, all the time. The SmartlockPro Self-Test GFCI tests itself even if you forget. Designed to meet the latest UL standard for auto-monitoring (self-test) our complete line of self-test GFCIs periodically conduct an automatic internal test to confirm that it can respond to a ground fault. With the slimmest profile on the market, the device allows for fast and easy installation, while Leviton’s patented reset lockout mechanism prevents reset of the GFCI if it is not wired or operating correctly. The SmartlockPro Self-Test GFCI is the smart choice in ground fault circuit interrupter protection. Item Description 15 Amp, 125 Volt Receptacle/Outlet, 20 Amp Feed-Through, Tamper-Resistant, Self-test SmartlockPro GFCI, Monochromatic, back and side wired, nylon wallplate/faceplate, screws and self-grounding clip included - White Technical Informat AC Horsepower Ratings At Rated Voltage: 1 HP Electrical Specifications Dielectric Voltage: Withstands 1250VAC per UL 943 and CSA-C22.2 No. 144.1-06 Short Circuit Current Rating: 10KA Temperature Rise: Max 30C after 100 cycles OL at 150 percent rated current Environmental Specifications Flammability: Rated V-2 per UL94 Operating Temperature: -35C to +66C Material Specifications Face Material: Thermoplastic Body Material: Polycarbonate Line Contacts: Brass Double Wipe .031 Thick Terminal Screws: Plated Steel Grounding Screw: Plated Steel Yoke: Zinc-Plated Steel Clamps: Brass Notes: w/ Wallplate Mechanical Specifications Terminal ID: Brass-Hot, Green-Ground, Silver-Neutral Terminal Accom.: 14-10 AWG Product ID: Ratings are permanently marked on device Product Features Feature: Self-Test Amperage: 15 Amp Voltage: 125 Volt NEMA: 5-15R Pole: 2 Wire: 3 Trip Level: Class A, 5mA plus or minus 1mA Termination: Back & Side Face Material: Thermoplastic Body Material: Polycarbonate Grounding: Self Grounding Color: White Strap Material: Galvanized Steel Standards and Certifications:UL/CSA Fed Spec WC-596: Yes Warranty: 2-Year Limited Grade: Residential Standards and Certifications NEMA: WD-6 ANSI: C-73 UL498: Yes CSA C22.2 No. 42: Yes NOM: Yes CSA-C22.2 No. 144.1-06: File LR-57811 MIL-SPEC: A-A-55459-SB UL 943: File E48380 Fed Spec WC-596: Yes Features and Benefits Provides continuous ground fault protection – detects and trips on actual ground fault even when self-test is being conducted On initial power up, tests the GFCI within 3 seconds Auto-monitoring exceeds the UL requirement Auto adapts and shifts to more frequent testing if potential problem is detected Status Indicator Light provides simple, intuitive feedback on power and protection status as well as indication of line/load reversal Patented Lockout Action prevents reset if GFCI is damaged and cannot respond to a ground fault Electronics are designed to minimize any false triggers Reduced depth makes it easier to install in any electrical box, even shallow ones Terminals allow for easy wiring options – back and side wire capable External back wire clamps provide visual indication of proper wire seating Withstands high torque and resists wire pullout Standard brass self-grounding clip Trip threshold meets or exceeds UL requirements for tripping time Improved immunity to high-frequency noise reduces nuisance tripping Advanced electronics design provides superior resistance to electrical surges and over-voltages Compatible with all Decora devices and wallplates; available in select Decora colors UL Fed Spec WC-596 rated. Support Instruction Sheet Product Bulletin What you see on pictures, that you will get!!! This item is BRAND NEW. This is the exact product you would see in a showroom, for less money! ENLARGE PICTURES FOR BETTER VIEW PLEASE VIEW THE PICTURES AND CONTACT ME WITH ANY QUESTIONS!!! Please check my other items!!!
