Leviton Ossmt-mdw Ultrasonic/infrared, Dual-relay Multi-technology Wall Switch

US $100

Lakewood, New Jersey, United States
Jan 29th

Open on mobile:
QR code

Leviton OSSMT-MDW Ultrasonic/Infrared, Dual-Relay Multi-Technology Wall Switch sensor, 2400 Sq. Ft Major & 400 Sq. Ft Minor Motion Coverage, White Leviton OSSMT-MDW Multi-Tech PIR/Ultrasonic Occupancy Sensor Decora Wall Switch, White Automatic Lighting Switch Provides Energy Savings and Convenience for Large Applications Overview Replaces a regular wall switch and automically turns lights on when someone enters a room Increases energy savings by turning lights off after only momentary occupancy Integrated photocell prevents lights from turning on when the room has adequate natural light Combination of PIR and ultrasonic technology provide excellent motion sensitivity Self-adaptive technology has been designed for "install and forget" use Choice Replacement for: Hubbell BA LH-MT, Mytech LH-MT, Hubbell BA LIGHTHAWK-MT, Bryant LIGHTHAWK-MT, Mytech LIGHTHAWK-MT, Novitas 01-BAS260, Bryant MSDTW, Bryant MSUSW, Bryant MSUSRW, Hubbell Wiring ATD1277W, Hubbell Wiring ATD1277HW, Hubbell Wiring ATU1277W, Hubbell Wiring ATU1277RRW, Lutron LOS-SUS-WH, Novitas 01-220, Novitas 01-250, Wattstopper DW-100-W, Wattstopper UW-100-W Product Features: Switch Type: Single-Pole Adjustment: Self-Adjusting Technology: Multi-Technology PIR/Ultrasonic Pattern Degrees: 180 Coverage Range Sq. Ft.: 2400 Time Adjustment: 30s-30m Load Rating: 800W@120V INC 1200VA@120V 2700VA@277V FL Voltage: 120/277 Volt AC 60Hz Wiring Neutral / Ground: Neutral Required Photo Cell: Ambient Override OFF Color: White Standards and Certifications: UL/CSA Warranty: 5-Year Limited Code Compliance: California Title 24 Features and Benefits: Self-Adaptive Technology: callbacks for adjustment are eliminated. Time delay and sensitivity settings are continually adjusted to occupant patterns of use in auto adapt mode. Exclusive Walk-through Feature: provides increased energy savings by not leaving the lights ON for an extended period after only momentary occupancy. Maximum Reliability, Low Cost: All digital circuitry uses a minimum of components. Convenient Push-Button: Provides manual ON/OFF light switch at any time. Fast, Simple Installation: Fits in a standard wall box and replaces a single-pole wall-switch; neutral and ground connection required. Sensor can be ganged together with other units in a multiple-switch wallplate. Adjustable Horizontal Field of View (PIR): May be adjusted between 180 degree and 32 degree of arc by using integral blinders located on either side of the lens. Optional Manual Adjustments for Delayed OFF Time Settings: Allows customized adjustments to maximize energy savings. Ambient Light Recognition: Integrated photocell prevents lights from turning ON when the room is adequately illuminated by natural light. Small Motion Sensitivity (US): The ultrasonic technology provides excellent small motion sensitivity. True Zero-Cross Relay: Switches at the zero crossing point of the AC power curve to ensure maximum contactor life and compatibility with electronic ballasts. Essential Info A standard passive infrared (PIR) occupancy sensor switch is appropriate for use in areas with an unobstructed view of the sensor and where motion coverage is within the sensor's range. For large applications, consider using the Leviton Multi-Tech PIR/Ultrasonic Occupancy Sensor Decora Wall Switch which uses both PIR and Ultrasonic technology. It works well to turn lights ON when a person enters a room and OFF when they leave. The ultrasonic technology is ideal for spaces such as private offices, small open offices, restrooms, hallways, conference and meeting rooms, irregular shaped rooms, rooms with partitions and storage areas where the switch location does not permit direct line-of-sight to the PIR. It also features walk-through sensing that provides increased energy savings by not leaving the lights ON for an extended period after only momentary occupancy. It even analyzes room conditions and adapts to errors or changing environment; resulting in less false reading and greater convenience and energy saving. With a 180° field of view and up to 240 square feet of coverage, a single Multi-Tech switch can do the same job as multiple standard PIR switches. By limiting a switch to operation only when a room is being occupied, you can decrease the amount of energy being consumed on a daily basis. Important notes: Smarthome does not offer technical support on this product, please contact the manufacturer directly for all product support. Defective exchanges for identical item within 30 days of purchase. After 30 days, please contact the manufacturer. Manufacturer contact information: Leviton Dept: 00244 Tel: (951) 894-4752 Manuals/Software Owner's Manual Product Data What's Included Multi-Tech PIR/Ultrasonic Occupancy Sensor Decora Wall Switch, White Owner's Manual More Info Compatibility The Leviton Multi-Tech PIR/Ultrasonic Occupancy Sensor Decora Wall Switch is compatible with incandescent lamps, electronic and magnetic low-voltage ballasts, electronic and magnetic ballasts, and fans. Enhanced Adjustment Options Blinders: Integral sliding blinders on each side of the lens may be used to restrict the 180° field of view down to 32°. This will prevent unwanted detection in areas such as hallways. Time: The delayed OFF time is preset at 30 minutes in the Auto Adapting mode. A choice of four delayed-OFF time settings is available: 30-seconds (for walking test purposes only), 10, 20, and 30 minutes for fixed time and auto adapting. The LED will flash when the adjusting knob is set to the indicated time value. Range (PIR): Adjusting the range allows the unit to ignore motion at the far end of its range and avoid unnecessarily switching lights ON. The range can be adjusted from 100% to 35% of the total coverage area. Sensitivity (US): Users can adjust internal ultrasonic operation to maximize detection of motion while minimizing the effects of environmental noise (electrical noise, air currents, temperature changes, etc.). Adjustment is made by pushing the ON-OFF button in a prescribed sequence to Low-Medium-High sensitivity Light: The OSSMT is factory preset without any ambient light override in effect. This means the unit will switch lights ON when it detects occupancy, regardless of the amount of natural sunlight present. To maximize energy savings in some installations, the ambient light override feature will prevent the unit from switching lights ON when there is ample natural sunlight, regardless of occupancy. This adjustment should be made when the ambient light is at the level where no artificial light is needed. Push-Button Manual Override Control: For manual control, the there is a convenient push-button switch. If the lights are OFF, pressing the button will turn lights ON and keep them ON for as long as the room is occupied. The lights will be turned OFF once the room is vacant, after the delayed-OFF time expires. Manual-ON/ Auto-OFF Mode: In this mode, the unit will not turn lights ON automatically when motion is detected. Lights can only be turned ON manually by pressing the push-button. The lights will remain ON as long as the unit detects activity in the sensor zones. It will shut lights OFF automatically after the space becomes unoccupied and the delayed-OFF time expires. Specifications Specifications Manufacturer: Leviton Manufacturer Product No.: OSSMT-MDW UPC: 078477279373 Minimum Load: No Minimum load required Maximum Load: Incandescent: 800W@120V INC; Fluorescent: 1200VA @ 120V; Fluorescent: 2700VA @ 277V; Supplemental: 1/4hp-5.8A @ 120V Voltage: 120/277 Volt AC 60Hz Switch Type: Single-Pole Technology: Multi technology PIR/Ultrasonic Pattern Degrees: 180 Coverage Range: 2400 square feet Time Adjustment: 30 seconds to 30 minutes Requirements: Neutral wire required Photocell: Ambient Override OFF Dimensions: 1.75" W x 4.06" T x 1.85" D Color: White Warranty: Manufacturer 5 year, limited Certifications: UL, CSA Images/Video Single-Pole Application 3-Way Wiring Application Field Of View Control Panel Diagram Reviews Product Specifications Part Number : OSSMT-MDW Color: White Item Package Quantity: 1 Technical Details Self-Adaptive Technology: Callbacks for adjustment are eliminated, time delay and sensitivity settings are continually adjusted to occupant patterns of use in auto adapt mode Convenient push-button provides manual ON/OFF light switch at any time Exclusive automatic "walk-through" sensing increases energy savings by shutting lights within 2 1/2 minutes after momentary occupancy OSSMT is ideal for private and Executive offices, conference rooms, storage areas, restrooms, classrooms, lounges, and training areas, or areas where minor motion is likely to occur Fast, simple installation: fits in a standard wall box and replaces a single-pole wall-switch Product Description From the Manufacturer Leviton's OSSMT multi-technology Decora brand style wall switch occupancy sensor is used to provide automatic lighting control for energy savings and convenience in a variety of commercial applications, including: - retrofit- private and executive offices- conference rooms- storage areas- restrooms- classrooms- lounges- training areas. The OSSMT provides for automatic switching of incandescent lamps, low-voltage lighting with electronic and magnetic transformers, and electronic and magnetic fluorescent ballasts. The OSSMT features a manual override switch that can be used to keep lights off while an area is occupied, which may be desired in conference rooms, classrooms and other areas during video presentations. Designed to replace a single-pole Decora wall switch, it fits in a standard wall box. The OSSMT-md model requires a neutral and a ground connection. For retrofit applications, the OSSMT-GD model does not require a neutral wire for installation. Leviton Multi-Technology Wall Switch sensor, 2400 Sq. Ft. Major Motion Coverage, Commercial Grade - White no. OSSMT-MDW. Wall Plate not included with Occupancy Sensors. Product Description 800W@120V INC 1200VA@120V 2700VA@277V FL, 120/277 Volt AC 60Hz, Single-Pole, 180 Degree, 2400 Sq. Ft. Coverage, Decora Multi-Technology PIR/Ultrasonic Wall Switch Occupancy Sensor, Commercial Grade - White California Title 24 Compliant, UPC: 07847727937

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	LEVITON
Model	OSSMT-MDW
