Leybold-heraeus Ultratest M2/m2ds/m2by Helium Leak Detector

US $1400

Longmont, Colorado, United States
Jun 10th

Open on mobile:
QR code

Leybold-Heraeus, #WAU500/D90A, Verti Pump System also available at additional cost, ask about package pricing!!! Equipped with (buyer to verify details: Leybold-Heraeus NT 150/360 Frequency Converter (see below for details) GENERAL SPECIFICATIONS FOR MACHINE AS FOLLOWS: Smallest Detectable Leak w/Options Quick-Test: 10-6 atm cc/sec w/out Quick-Test: 2x10 -10 atm cc/sec w/out Quick-Test w/reduced Pumping Speed: 2x10 -11 atm cc/sec Full Scale Leak-Rate Meter Reading w/out Quick-Test: 10x10 -9 to 10x10 -6 atm cc/sec w/Quick-Test: Must multiply meter reading by correction factor (see manual Section 4-3-2) Maximum Safe Operating Pressure In the Mass Spectrometer (PIII) 1x10 -4 mbar Detectable Masses: 3 and helium 4 Adjustable Emission Current: 0.6 to 5mA Total Pressure Reading Thermovac (PII): 10 -3 to 1000 mbar Ionization Gauge (PIII): 10 -6 to 10 -3 mbar Maximum Gas Flow @ Test Port: 2x10 -3 atm cc/sec Pumping Speet @ Test Port and In Mass Spectrometer Ultratest M2: For Helium 20 ltr/sec For Air 7.5 ltr/sec Ultratest M2DS/M2BYTC/M2BYPC: For Helium 16 ltr/sec For Air 6 ltr/sec Backing Pump: Trivac Vane Pump M2 and M2DS: D2A (2.2cfm or 1.1 ltr/sec displacement) M2BYTC/M2BYPC: D4A (4.5cfm or 2.1 ltr/sec displacement) Pump Vluis for Trivac: HE-200 Diffusion Pump: Leybodiff 180L Pumping Speed For Air: 180 ltr/sec (381cfm) at 10 -5 mbar; throtted to approx. 2 ltr/sec Pump Fluid For Diff. Pump: HE-300 (50cc optimum) Cold Trap Capacity: 2.4 qts of liquid nitrogen (LN2) Holding Time: Approx 20 hrs w/one Filling Outputs - Recorder Socket But Pin 5 (+) to Pin 3: 0 - 10 VDC (10 VDC is full scale deflectio of leak-rate meter) Pin 1 (+) to Pin 3: 1 - 7 VDC in 1 volt steps corresponding to the 7 leak-rate positions on the range switch. The output is 0 when the range switch is not in a leak-rate position. Triggers 1 & 2 (Optional): 6 Amp, 220 VAC max. Mains Supply: 115V, 60 Hz Recommended Mains Fuse: 10 Amp Dimensions PK Unit: 22.8" x 16.3" x 16.5" Electronic Control Cabinet: 9.2" x 10.3" x 16.1" FB Remote Control Module: 8.7" x 9.1" x 5.1" Optional Quick-Test Housing: 8.4" x 6" x 3.2" Weights PK Unit: Ultratest M2: 154 lbs Ultratest M2DS: 165 lbs Ultratest M2BYTC/M2BYPC: 176 lbs Electrical Control Cabinet: 28.7 lbs FB Remote Control Module: 4.4 lbs Optional Quick-Test Housing: 5.5 lbs Data for Optional Quick-Test Smallest Detectable Leakrate: 10 -6 atm cc/sec Gas Throughput in Probe: Approx 90 atm cc/minute Sampled Gas Inlet to Leak Detector: Approx 10 - 3 atm cc/sec Connecting Flange: NW40KF Connecting Flange for Calibrated Leak: NW10KF Line Voltage: 60 Hz, 220 V Dimensions of Housing: 8.4" x 6" x 3.2" Weight of Housing: 5.5 lbs Probe PVC Tubing Length: 15' standard, up to 100' optionalff Response time for 15' tubing: Less than 2 seconds Weight: 1.1 lbs GENERAL SPECIFICATIONS FOR FREQUENCY CONVERTER AS FOLLOWS: Power Source Voltage: Single phase, 100/120/220/240 Frequency: 47-63 Hz (Currently set up for 120V / 60Hz) Steady Rate Max: 680 VA Transient (<0.5 Sec): 750 VA Output Values Voltage: 45 Vrms Rated Frequency: TMP-150: 840 Hz TMP-360: 760 Hz Max. Power: Acceleration: 380 Watts TMP-150 Normal Operation: 112 Watts TMP-360 Normal Operation: 260 Watts Relay Contacts: Maximum: 24 VDC & 240 VAC @ 8 A Mininum: 5 VDC @ 1 mA Environment Operating Temperature Range: 0 deg to 45 deg C Storage Temperature Range: -40 deg to +85 deg C Mechanical Design Dimensions approx (w x h x d): 8.39" x 5.08" x 11.42" Weight approx: 18.7 lbs Ultratest Module MS: 16 1/2" x 9 1/4" x 11" 180 lbs Ultratest PK Module: 29" x 29" x 26 1/2" 180 lbs Quick Test Module: 7" x 6" x 8 1/2" 10 lbs Cart For Machine: 43" x 25 1/2" x 34 3/4" 250 lbs Wooden Box of Parts: 56 1/2" x 56 1/2" x 24 1/2" 250 lbsPlease contact James Owen with any questions james@automatics.com
