Lm386n1 Low Voltage Power Audio Amp Dip8 8 Pin Dil

GBP 1.19

Huddersfield, United Kingdom
Feb 22nd

Open on mobile:
QR code

LM386N1 Low Voltage Power Audio Amp DIP8 8 pin DIL Amplifier IC Audio Amp 8 pin DIL 4 to 12 vdc 325 mW low voltage power amplifier which is available in a DIL-8 package. The gain is internally set to 20 but the addition of an external resistor and capacitor wil allow the gain to be set anywhere between 20 and 200. The LM386 is a power amplifier designed for use in low voltage consumer applications such as AM-FM radio amplifiers, intercoms, tv sound systems, line drivers, ultrasonic drivers, small servo drivers and power converters. Low voltage audio power amplifier 325mW output power 300kHz bandwidth 26dB gain 8Ω load impedance 4 to 12VDC supply voltage DIL-8 case 0 to +70°C operating temperature Business seller information Mallinson Electrical Contact details Mallinson Electrical 3 Silver Street West Aspley Huddersfield West Yorkshire HD5 9AG United Kingdom Phone:01484|549200 Email:sales@mallinson-electrical.com Value Added Tax Number: GB 873249010 Return policy To qualify for a hassle-free return, you must pay with PayPal and have the item shipped to a US address. The item must be returned in the same condition it was received. See terms and conditions - opens in a new window or tab. After receiving the item, open a return within Return shipping 30 days You pay return shipping

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Unit Quantity	1
Form	Audio Amp
Unit Type	Unit
Case	8 pin DIL
Brand	ST
Supply Voltage	4 to 12 vdc
MPN	820264
Level	325 mW
Type	Amplifier IC
