Lm393 Obstacle Avoidance Sensor Infrared Module Reflection Photoelectric Sensor

US $1.99

Hong Kong, Hong Kong
Jan 29th

Open on mobile:
QR code

Product Related 1. When the module detects an obstacle in front of the signal , the green indicator light on the board level , while low-level continuous output signal OUT port , the module detects the distance 2 ~ 30cm, detection angle 35 °, the distance can detect potential is adjusted clockwise adjustment potentiometer to detect the distance increases ; counterclockwise to adjust the potentiometer to reduce the detection distance . 2 .active infrared sensors to detect the reflected , and thus the shape of the reflectivity of the target detection range is critical . The minimum detection distance which black , white maximum ; small objects from a small area , a large area from the Grand . 3 . the output port OUT sensor module can be directly connected to the microcontroller IO port , you can directly drive a 5V relay ; Connection : VCC-VCC; GND-GND; OUT-IO 4 .using the comparator LM393, stable ; 5 .can be used for 3-5V DC power supply modules . When the power is turned on, the red power indicator light ; 6. with the screw holes of 3mm , easy fixed installation ; 7. board size : 3.1CM * 1.5CM 8. each module shipments comparing the threshold voltage has been adjusted by the potentiometer is good , not exceptional circumstances, do not arbitrarily adjust the potentiometer. Interface Description (3-wire): 1. VCC: external 3.3V-5V voltage (can be directly connected to 5v MCU and 3.3v MCU) 2. GND: GND External 3. OUT: small board digital output interfaces (0 and 1) Package Include: 1 x Infrared obstacle avoidance module Thank you for your bidding first! You are welcome to our new store, all our items are at very low price the item with high quality Shipping Our shipping cost includes the cost of the packaging box, the materials used to protect the product and/or all other materials used during the processing of the product, residential shipping fee, and handling fee. Payment Before you bid, we want to let you know that we accept Paypal Only. Please pay for it as soon as possible after you win the bid. We would send it out in the current work day, or the next work day. Return Policy We guarantee refund cash in 30 days. But the buyer should afford the shipping charges. Our Guarantee 100% brand new 100% speed shipment 100% customer satisfaction Welcome to our Store
