Lmh6505 Linear-in-db Variable Gain Opamp Vca 100mhz X2 -:

US $9.20

Valley Stream, New York, United States
Jan 29th

Open on mobile:
QR code

LMH6505MA Linear-in-dB Variable Gain Amplifier 100MHz Case: SOIC8 Lot Size: 2 units See other listings and lot sizes for this item See other VCAs 100MHz Linear-in-dB Voltage Controlled Variable Gain OpAmp National The LMH6505 is a wideband DC coupled voltage controlled gain stage followed by a high-speed current feedback op amp which can directly drive a low impedance load. The gain adjustment range is 80 dB for up to 10 MHz which is accomplished by varying the gain control input voltage, VG. Maximum gain is set by external components, and the gain can be reduced all the way to cut-off. Power consumption is 110 mW with a speed of 150 MHz and a gain control bandwidth (BW) of 100 MHz. Output referred DC offset voltage is less than 55 mV over the entire gain control voltage range. Device-to-device gain matching is within 0.5 dB at maximum gain. Furthermore, gain is tested and guaranteed over a wide range. The output current feedback op amp allows high frequency large signals (Slew Rate = 1500 V/us) and can also drive a heavy load current (60 mA) guaranteed. Near ideal input characteristics (i.e. low input bias current, low offset, low pin 3 resistance) enable the device to be easily configured as an inverting amplifier as well. To provide ease of use when working with a single supply, the VG range is set to be from 0V to +2V relative to the ground pin potential (pin 4). VG input impedance is high in order to ease drive requirement. In single supply operation, the ground pin is tied to a "virtual" half supply. The LMH6505's gain control is linear in dB for a large portion of the total gain control range from 0 dB down to -85 dB @ 25degC. This makes the device suitable for AGC applications. For linear gain control applications, see the LMH6503 . Datasheet I only ship to buyer's EBAY shipping address IMPORTANT: Buyer controls combining of order, by making a single payment for all items. Multiple payments void any shipping discounts. Can only combine BEFORE payment, never after. How to combine orders. If you have ANY time constraints, contact seller BEFORE buying or bidding, so we can BOTH come to an agreement. INTERNATIONAL shipments will NOT have online tracking , unless you use REGISTERED MAIL -- contact seller for invoice. INTERNATIONAL transit time can be 6-28 business days, and can be delayed by local Customs backlogs. If this is not acceptable, we cannot not enter into any trade. US shipments can take 5-7 business days - however the USPS does NOT guarantee these transit times, and can exceed them. eBay tracking info has 24-48 hrs update latency and can only guarantee a delivery scan -- interim scans may not occur. ALL items shipped to buyer's Registered eBay shipping address address, without exception. We can never take an address from email. Payment closes order. No changes are possible once paid. We have no expedited shipping service outside USA -- If urgent, please source locally. International : If you want seller to be responsible for package in transit , you must choose Registered mail - adds $13 to S&H - contact seller for invoice. supreme supremewidgets supremeauctiononlinesoftware.widgets.EbayGalleryZ.swf supremewidgets supremeauctiononlinesoftware.widgets.GalleryCat.swf supremewidgets supremeauctiononlinesoftware.widgets.FeedbackWidgetBasic.swf

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	OEM
Model	LMH6505MA
MPN	LMH6505MA
Country/Region of Manufacture	United States
