Ludlum 12 & 44-3 Scintillator Survey Meter Radiation Detector Geiger Counter,G,X, US $395 – Picture 0

Ludlum 12 & 44-3 Scintillator Survey Meter Radiation Detector Geiger Counter,G,X, US $395 – Picture 1

Ludlum 12 & 44-3 Scintillator Survey Meter Radiation Detector Geiger Counter,g,x

US $395

Tucson, Arizona, United States
Nov 17th

Open on mobile:
QR code

Super clean Ludlum model 12 and 44-3 low energy scintillator probe gamma, and X-ray detector. Model 12 survey meter 0-10,000 CPS and 0-2.5 kV. in four decades. Fast / slow response switch, audio on / off switch, and reset button. high voltage test button Powered by 2 D size batteries up to 2,000 hrs. with alkaline. This model runs $300.00+ more than model 3 due to the extended high voltage range, direct reading high Voltage meter, and adjustable threshold / discriminator. Read out in C.P.S. counts per second provides much faster rise and wider spread than C.P.M. Adjustable regulated high Voltage will support scintillators, GM detectors, proportional, and other than 900 Volt probes. This instrument favors scintillation and proportional probes, and still very usable with GM detectors. Just calibrated in C.P.S. as well as setting threshold at 10mV, and calibrated high Volt meter. This instrument came from a medical lab and was very well cared fore. The 44-3 scintillator probe was refurbished and has a new 1" X 1mm Nai(TI) crystal $175.00 from Ludlum like new sensitivity ( NO PETRI DISH CRYSTAL HERE ) photo 7 shows normal background photo 8 shows response to a Tritium key fob ( try that with an old crystal ) has been checked with various isotopes for efficiency as stated by the Ludlum specifications. The following data is from Ludlums web site for model 12. COMPATIBLE DETECTORS: GM, proportional, scintillation HIGH VOLTAGE: adjustable from 400-2500 Vdc THRESHOLD: -1 to -100 mV WINDOW: no OVERLOAD: optional LINEARITY: within 10% of true value with detector connected CONTROLS: Rotary Selector Switch: off, battery check, range selections for x1, x10, x100, x1000 Reset Button: to zero meter High Voltage Check Button: view high voltage reading on meter face Response Switch: toggles between FAST (4 seconds) or SLOW (22 seconds) from 10% to 90% of final reading Audio Switch: on/off, built-in unimorph speaker, 60 dB at 61 cm (2 ft) Calibration Controls: accessible from front of instrument (protective cover provided) CONSTRUCTION: cast and drawn aluminum with beige powder coating METER DIAL: 0-500 cpm, 0-2.5 kV, BAT TEST (others available) DETECTOR CONNECTOR: type "C" series TEMPERATURE RANGE: -20 to 50 °C (-4 to 122 °F)May be certified for operation from -40 to 65 °C (-40 to 150 °F) POWER: two each “D” cell batteries (housed in externally accessible sealed compartment) BATTERY LIFE: 2000 hours SIZE: 16.5 x 8.9 x 21.6 cm (6.5 x 3.5 x 8.5 in.) (H x W x L) WEIGHT: 1.6 kg (3.5 lb) including batteri See Ludlums web site for more details at this link http://www.ludlums.com/ Includes Ludlum model 12, coil cord, right angle bnc adaptor 44-3 probe, two new D size batteries, and some active sources as seen in photos. ( I don't recommend attaching a source to the instrument with this high sensitivity probe as false readings can occur.) SIGN NOT INCLUDED
