M/a-com Microwave Switch Ma7531-s046

US $40.00

King George, Virginia, United States
Jun 9th

Open on mobile:
QR code

M/A-COM Microwave Switch MA7531-S046 MRC Parameter Characteristics AAQL Body Style Rectangular ABHP Overall Length 2.420 inches minimum and 2.460 inches maximum ABKW Overall Height 1.310 inches minimum and 1.350 inches maximum ABMK Overall Width 1.480 inches minimum and 1.520 inches maximum ACZB Frequency Rating 12.4 gigahertz minimum 1ST frequency rf power handling and 18.0 gigahertz maximum 1ST frequency rf power handling ACZB Frequency Rating 0.5 gigahertz minimum 1ST frequency insertion loss reference and 4.0 gigahertz maximum 1ST frequency insertion loss reference ACZB Frequency Rating 0.5 gigahertz minimum 1ST frequency voltage standing wave ratio and 4.0 gigahertz maximum 1ST frequency voltage standing wave ratio ACZB Frequency Rating 0.5 gigahertz minimum 4TH frequency rf power handling and 4.0 gigahertz maximum 4TH frequency rf power handling ACZB Frequency Rating 12.4 gigahertz minimum 4TH frequency insertion loss reference and 18.0 gigahertz maximum 4TH frequency insertion loss reference ACZB Frequency Rating 12.4 gigahertz minimum 4TH frequency voltage standing wave ratio and 18.0 gigahertz maximum 4TH frequency voltage standing wave ratio ACZB Frequency Rating 8.0 gigahertz minimum 2ND frequency rf power handling and 12.4 gigahertz maximum 2ND frequency rf power handling ACZB Frequency Rating 8.0 gigahertz minimum 3RD frequency insertion loss reference and 12.4 gigahertz maximum 3RD frequency insertion loss reference ACZB Frequency Rating 8.0 gigahertz minimum 3RD frequency voltage standing wave ratio and 12.4 gigahertz maximum 3RD frequency voltage standing wave ratio ACZB Frequency Rating 4.0 gigahertz minimum 2ND frequency insertion loss reference and 8.0 gigahertz maximum 2ND frequency insertion loss reference ACZB Frequency Rating 4.0 gigahertz minimum 2ND frequency voltage standing wave ratio and 8.0 gigahertz maximum 2ND frequency voltage standing wave ratio ACZB Frequency Rating 4.0 gigahertz minimum 3RD frequency rf power handling and 8.0 gigahertz maximum 3RD frequency rf power handling AEEA Switch Type Transfer AFGA Operating Temp Range -20.0/+85.0 deg celsius AHUC Coaxial Connector Series Designation SMA AHUD Connector END Design Female AKPJ Actuator Voltage IN Volts 20.0 minimum and 30.0 maximum AKPN Switch Operation Sequence Breaks before makes AKPP Switching Time 20.0 milliseconds AKRC Coupling Position Quantity 2 TTQY Terminal Type AND Quantity 2 tab, solder lug and 4 receptacle, coaxial For questions call 5407750495 or email
