M22520 2 01 Series Positioner Kit Seven Series Positioner And Work

US $45.51

Whitney Point, New York, United States
Aug 12th

Open on mobile:
QR code

Package Include: 7 K series K40+K41+K42+K43+K709+K13-1+K330-3 and SK2/2 adjustable positioner Match tool: YJQ-W1A/ACT-M101/YJQ-MH800/YJQ-MH992/AFM8/YJQ-W1Q/WA22/WA22AE/615717 Connector: Suitable for MIL-DTL-38999 SERIES 1, 2, 3, 4, MIL-DTL-83733 , MIL-DTL-24308, MIL-DTL-83527, SAE AS81659 SERIES 2 (ARINC 404), SAE AS81511 SERIES 3,4, SAE AS81714 SERIES 2 Used to locate contacts horizontally and vertically between the indenters of the tools to ensure the accuracy and consistency of the crimp position. Product Description How to Install the Positioner 1. Before installing the positioner, the tool should be open 2. Remove the safety clip from positioner guide 3. Select the correct positioner for terminal crimping 4. Insert the positioner into positioner guide, push down and then rotate 90 °, until bayonet pins lock 5. Remove the spring clip from the selector knob, adjust it to the correct selector position Specifications Material:Stainless Steel Body Colour:Blue Every Positioners Dimension(in):0.94*0.93 8 Positioners Weight(lb):0.212 K40(M22520/2-07): MS27490-22&22M&22D,MS27655-22D K41(M22520/2-06): MS27491-22&22M&22D,MS27492-22&22M&22D,M24308/12-1 K42(M22520/2-09): MS27493-22&22M&22D,MS27494-22&22M&22D,M24308/13-1 K43(M22520/2-10): MS27490-20,MS27491-20,MS27492-20,MS27493-20,MS27494-20,MS27655-20 K13-1(M22520/2-08): M24308/10-1,M24308/11-1,M39029/11-20-20,M39029/12-20-20,RG55B,58C,223/U K330-3: M39029/22-22-22; CTS-S/22-22 K709(M22520/2-37): M39029/90-529,/91-530/113-625,/114-628 K709(M22520/2-37): M39029/90-529,/91-530/113-625,/114-628 SK2/2: SK2/2 Universal Positioner is suitable for the positioning of a small part of round contacts of MIL standard; Why Choose Us JRready Tools is a company producing professional tools and providing services in the manufacture of wire harness and connectors which are used in the fields of aviation,aerospace,electric vehicles,marine,etc.Years of accumulation,the company has unique advantage in manufacturing four-indent crimp tools.It possesses mature technology from product design to product manufacture.the company insists excellent product quality and strives to provide customers with best service and perfect experience. JRready YJQ-W1A(AFM8) Aviation Hand Crimp Tools Wire Cable Pin Socket Crimper for Cable Assembly 20-32AWG JRready YJQ-MH800 ULTRA-PRECISION tool of afm8 Suitable for aviation miniature connectors,20-32AWG Aviation Contacts Crimp Tool KIT ST1010: YJQ-W1A+K13-1+K40+K42+K43 JRready ST1060 Tool Kit,YJQ-W1A Crimper M22520/2-01&Ideal 45-416 Wire Stripper&11 AFM8 Positioners&G125 Gauge&DAK20 DRK20B Installing Removal Tool JRready Four indent Crimp Tool Kit ST2060: YJQ-W1A Crimper+Seven Positioners+G125 Go-NoGo Gage JRready Four indent YJQ-W1A(M22520/2-1/AFM8) SERIES Crimp Tool Kit ST2119 for wire/cable contact/pin/socket/terminal Crimping in Connector 20-32AWG JRready JRD-AF8 Crimping Tool M22520/1-01 Solid Contact Crimper High Precision Electrical Connectors Crimp Tool 12-26 AWG JRready ACT WN10 Wire Cutter JRready Tool Kit ST2060S：ST2060 Super version KIT & ideal Wire Stripper 45-416 AWG Standard JRready ST5142 Removal and Installing Tool Kit:DRK12B+DRK16B+DRK20B+DAK12B+DAK16B+DAK20B Removal and Installing Tool Kit JRready ST5163 (HT250-4 Adjustable Retention Tester KIT with 4 Pin/Socket Tester Tip) test tool for correct assembly of 20# & 22# contact/terminals/pin/socket in electronic connectors JRready ST6110 DT Connector Kit Gray Connectors 2-12 Pin/Deutsch Solid Terminals with YJQ-W2DT Crimper 4.8 inches x 2.9 inches x 1.4 inches. Weight: 4.8 oz

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Does Not Apply
MPN	Does not apply
Type	Does not apply
UPC	7445010885835
ISBN	Does not apply
EAN	07445010885835
