M328 Lcd 12864 Transistor Tester Diy Kits Diode Triode Capacitance Lcr Esr Meter

US $1900

shenzhen, China
Jun 21st

Open on mobile:
QR code

M328 LCD 12864 Transistor Tester DIY Kits Diode Triode Capacitance LCR ESR Meter Description 100% Brand New & High Quality. NOTE: DIY kits ,need solder it by yourself Multi-functional transistor tester for automatic detection of NPN and PNP transistors, N-channel and P-channel MOSFET, diodes, thyristors, resistors, capacitors or other devices. Also can be used as frequency meter or square signal and PWM signal generator. Features: Digital 12864 LCD display, easy to read. Can be powered by 9V battery(not included). Automatically detect NPN and PNP transistors, N-channel and P-channel MOSFET, JFETs, diodes, inductors, resistors, capacitors, thyristors or other devices. Support 2 resistors measurement, also support potentiometer measurement. Automatically test the pins of a component and show on the display. Measure the gate threshold voltage and gate capacitance of the MOSFET. Measure bipolar transistor current amplification factor and base-emitter threshold voltage. Short detection time: only 2 seconds. It costs more time for bulk capacitor detection. Can be used as signal generator and frequency meter. Different built-in square signals from 1Hz-2Mhz are available to choose. It can generate 1-99% PWM(pulse width modulation) signals. How to use: 1. Resistor welding. If you are not familiar with the chromatic circles, please check the resistance with a multimeter. 2. Other components welding. Please make sure the transistor type and direction are correct. 3. Connect with power supply(9V battery or 5.5V-12V external DC power supply) instead of connecting with M328 and the LCD. Then measure the voltage between pin 7 and pin 22 with a multimeter. If the voltage is +5V, it means the meter is working in normal condition. 4. Cut off the power supply, connect with M328 and the LCD. When all installation finished, connect with the power supply. 5. Detailed installation guide: https://www.dropbox.com/sh/uo7nr7xet09esbu/AAAMAjU0sE2hFqCXe0VAsGM_a?dl=0 Note: The testing picture is just for reference, please in kind prevail! Specifications: Display: 12864 Voltage: DC5.5-12V Current: 24mA Power Supply: 9V Battery(not included) Resistance Measurement: Max.50MΩ Resistance Resolution: 0.1Ω Capacitance Measurement: 25pF~100mF Capacitance Resolution: 1pF Inductance Measurement: 0.01MH~20H Screen Size: 5 * 3.5cm / 2 * 1.4in PCB Size: 7.5 * 6cm / 3 * 2.4in Package Size: 9.5 * 9.5 * 3.5cm / 3.7 * 3.7 * 1.4in Package Weight: 81g / 2.8oz Package including: 1PCS * Transistor Tester DIY Kit Payment We accept PayPal payment only. Please make sure you have a valid PayPal account before purchase (You may apply paypal account at www.paypal.com). Please make payment in 3 days after purchase If you buy multiple items, you may make one payment for all the items instead of paying for them individually. Delivery details Orders will be processed and dispatched within 24-48 hours after payment is clear. We only deliver to confirmed eBay addresses. Your eBay address MUST MATCH your Shipping address. After we send the items, we will keep on tracking the parcels,if you have not received your items within 30 business days from payment, please contact us and we get back to you soon. Normally the parcels are delivered by Airmail, reach most of the countries within 10 - 20 business days. Please note that estimated delivery time also depends on your local post service and customs clearance process etc. Country Delivery Time (days) Not including Handling time, weekend, and holidays 9-12 13-18 19-24 25-29 30-35 >35 United States 5% 50% 30% 11% 5% Refund United Kingdom 10% 63% 19% 3% 4% Refund Australia 21% 50% 14% 7% 7% Refund France 11% 29% 44% 10% 7% Refund Germany 11% 22% 30% 21% 16% Refund Canada 0% 47% 31% 18% 4% Refund Spain 4% 25% 48% 13% 11% Refund Terms of sales We offer 14 days return policy. Please contact us in 14 days for any issue about the items after you receive. All returned items MUST BE in the original packaging and you MUST PROVIDE us with the shipping tracking number, specific reason for the return and your eBay ID.We will refund YOUR FULL WINNING BID AMOUNT upon receipt of the item,Buyer is responsible for return shipping cost. We check every item carefully before send them, if the item is damaged during transportation, please take photos of the damaged items in 48 hours and send to us by email after you receive the parcels, we will resend it or refund. About us We try our best to offer best serive, best quality and best price to maintain high standards of excellence and strive for 100% customer satisfaction! Feedback is very important for us. Please contact us immediately BEFORE you give us neutral or negative feedback.We will reply you soon and we will be very appreciated for your cooperation. Contact us We will reply you in 48hours after receive your emails. We are appreciated for your POSITIVE feedback. Please do NOT leave negative feedback without asking for help. Our aim is offering you Top Level Customer Service and we will try our best to solve any problem you have. Serious Buyer Only! Please place bid only if you agree with all the terms,thank you. Enjoying your online shopping at our store! Wholesale is welcome.
