Machinist Made 4" Dia. x 1" Drawbar Face Plate 4 Clamps Tool Diemaker Grinder, US $1200 – Picture 0
Machinist Made 4" Dia. x 1" Drawbar Face Plate 4 Clamps Tool Diemaker Grinder, US $1200 – Picture 0

Machinist Made 4" Dia. X 1" Drawbar Face Plate 4 Clamps Tool Diemaker Grinder

US $1200

  • Flint, Michigan, United States
  • May 24th
Open on mobile:
QR code
............I personally machined and ground this hardened 4" dia. and 1" thick face plate and four clamps............All holes are 10-32 tapped except the 1/4" tapped center hole on the face and the 5/16" tapped center hole on the back for threaded rod drawbar...........The first two or three threads are popped on the 1/4" tapped hole but still plenty of good threads............Please view the photos and judge the condition for yourself............This has been invaluable to me as a tool grinder.......It has been used a lot by my coworkers and I...........My initials are on the clamps..........I hope someone has a need for it............  ...............I am a retired Tool & Die Maker, and precision Tool Grinder of 40+ years.............The last 33 years as a Tool Grinder..............I have been retired for 10 years now   and am in the process of selling my tools..............
