Machinists Mill Lathe Toolmaker Set Up Angle Plate Fixture

US $100.00

  • Sterling Heights, Michigan, United States
  • Apr 24th
Open on mobile:
QR code
This article is about the Machinists Mill Lathe Toolmaker Angle Plate Fixture which has a hardened and ground surface with a tolerance of .0002. The angle plate fixture has a .625 step and a 1.187 step, with a 3.000 range. The precision detail of the angle plate fixture is shown through many pictures. It has threaded holes on its face and base, with a 3/8-16 on face and 3/8-16 on base measuring 8.625 x 5.875 x 1.000. Thanks for your interest in this angle plate fixture. If there are any details missed, please feel free to contact the seller.
“GOOD CONDITION”
Manufacturer UNKNOWN
Brand SPECIAL MADE
Country/Region of Manufacture United States
