Magnetics Inc OF-44925-TC, F-193A-F TOROID FERRITE CORE. Lot of 5 cores, US $300 – Picture 0
Magnetics Inc OF-44925-TC, F-193A-F TOROID FERRITE CORE. Lot of 5 cores, US $300 – Picture 0

Magnetics Inc Of-44925-tc, F-193a-f Toroid Ferrite Core. Lot Of 5 Cores

US $300

  • Orange, California, United States
  • Jun 11th
Open on mobile:
QR code
MAGNETICS INC OF-44925-TC FERRITE CORE, TOROID,  F MATERIAL, Permeability 3000 You are buying a lot of 5 Part Number: F-193A-F Manufactured by Magnetics Inc, Pennslyvania, USA Core Type: Toroids Toroid Core Size: OD = 49.1 mm (1.932 inch) x ID = 31.8 mm (1.252 inch) x HT=19 mm (0.75 inch)   Material Grade: F Permeability of 3000, Max Permeability 4300 Saturation Flux density 4700 gauss  at 10 oersted, 25 deg C Residual Flux Density 900 gauss, Volume resistivity 100 ohms-cm, Curie temp 250 deg C. Le = Effective Magnetic Path Length: 12.3 cm  Ae = Effective Cross Section Area: 1.46 cm2  Ve = Volume : 18 cm3 Al = Inductance Factor : 4460 nH/t or mH/1000turns RoHS Compliant Application / Uses :  F material with permeability of 3000 is the most widely used ferrite core for switch mode power supplies in the 20 Khz to 300 Khz range. It is also used as EMI/RFI filters and common mode chokes for 1 Mhz to 50 Mhz.
