Marvell 7-port GE Switch - MVL88E6172-A1-TFJ2C000, US $8,125.00 – Picture 0

Marvell 7-port GE Switch - MVL88E6172-A1-TFJ2C000, US $8,125.00 – Picture 1

Marvell 7-port Ge Switch - Mvl88e6172-a1-tfj2c000

US $8,125.00

Casarea, Israel
Jan 29th

Open on mobile:
QR code

Marvell Link Street IC (88E6172) - Low Power 7-Port Gigabit Switch ITEMS INCLUDED (900) Marvell 88E6172 Low Power 7-port Gigabit Switch CONDITION BRAND NEW - SEALED IN ORIGINAL ANTISTATIC BAG FROM FACTORY DESCRIPTION Description: 7-Port GE Switch w/ 5 integrated PHYs w/ 1GMII, RGMII, and EEE Manufacturer: Marvell Model: MVL88E6172-A1-TFJ2C000 OVERVIEW The Marvell® 88E6172 IC device is a single-chip integrations of a 7-port Gigabit Ethernet switches with five integrated Gigabit Ethernet transceivers. This device supports “Best in Class” Quality of Service (QoS) and the highest “real world” performance. This device is uniquely suited for Small Office Home Office (SOHO) and Small-to-Medium Business (SMB) applications. The device contains five 10/100/1000 triple speed Ethernet transceivers (PHYs), one Gigabit SERDES(88E6176 device only), and two digital interfaces that support a combination of GMII, RGMII, MII, and RMII interfaces in a 128-pin QFP package. The device has a high-speed, non-blocking four traffic class QoS switch fabric that uses the unique Marvell Dynamic Queue Limit architecture. The QoS architecture switches packets into one of four traffic class queues based upon Port, IEEE 802.1p, IPv4 Type of Service(TOS) or Differentiated Services (DiffServ), IPv6 Traffic Class, 802.1Q VLAN ID, DA MAC address or SA MAC address. The device also contains a high-performance address look up engine with support for up to 8K active nodes, and a 1 Mbit frame buffer memory. Back-pressure and pause frame-based flow control schemes are included to support zero packet loss under temporary traffic congestion. The MAC units in the devices comply fully with the applicable sections of IEEE 802.3 and support frame sizes up to 10KBytes. The sixth and seventh ports’ interfaces support a direct connection to Management or Router CPUs with integrated MACs. These interfaces, along with BPDU handling for IEEE 802.1D Spanning Tree Protocol, 802.1w Rapid Spanning Tree, 802.1s Multiple VLAN Spanning Tree, programmable per-port VLAN configurations,802.1Q and Port States, support fully managed switches and truly isolated WAN vs. LAN firewall applications. The device supports 4,096 802.1Q VLAN IDs which can been abled on a per port basis. Three levels of 802.1Qsecurity is supported with error frame trapping and logging. The device supports multiple address databases (up to4096), which allows packet routing without modification of the MAC address. This allows the same MAC address to exist multiple times in the MAC Address database with multiple port mappings, to completely isolate the WAN from the LAN database. The 88E6176 device’s Gigabit SERDES interface sup-ports SGMII, 1000BASE-X and 100BASE-FX. It can be configured to act as the fifth or sixth port on the device. The PHY units in the device support the latest 802.3azEnergy Efficient Ethernet (EEE) standard. They are designed with Marvell® cutting-edge mixed-signal processing technology for digital implementation of adaptive equalization and clock data recovery. The device also integrates MDI interface termination resistors into the PHYs. This resistor integration facilitates board layout and reduces board cost by reducing the number of external components. Both the PHY and MAC units in the devices comply fully with the applicable sections of IEEE802.3, IEEE 802.3u, and IEEE 802.3x standards. The PHYs also include an integrated Advanced Virtual Cable Tester® (VCT™) enabling fault detection and advanced cable performance monitoring. The 88E6172 also supports Wake-on-LAN and Wake on Frame event detection allowing an attached CPU to enter sleep mode and enabling even greater system power savings. The device includes an integrated power monitor and reset controller which enables the 88E6172 to act as a system’s power reset controller and reducing BOM cost. Up to 12 LEDs can be directly driven by the device, which supports both single and dual color LEDs. The combining of multiple ports Link/Activity LED into a single LED is also supported. The devices many operating modes can be configured using SMI (serial management interface - MDC/MDIO).The devices also support a standalone QoS mode or configuration via a low cost serial EEPROM. The devices are designed for cost-sensitive Gigabit Ethernet switch systems that require Quality of Service,Tru4nking,Stacking, and/or Spanning Tree. Highlighted Features • Supports 802.3az Energy Efficient Ethernet • Wire speed performance with Maximum Frame sizeup to 10K Bytes • ‘Best-in-Class’ per port TCP/IP Ingress Rate Limiting along with independent Storm Prevention - Integrated power monitor and power reset controller - 5 Ingress Rate Limiting buckets per port, supporting Rate-based and Priority-based rate limiting - Non-Rate Limited frames based on SA or DA • Per port, programmable MAC hardware address learn limiting • Wake-on-LAN and Wake of Frame Event Detection • Layer 2 Policy Control List (PCL) enables drop,trap, or mirroring based on SA, DA, VID, Ethertype,VBAS, PPPoE, UDP, and DHCP Option 82 • Remote Management capabilities allow device configuration and readback via Ethernet frames • Per port, programmable MAC hardware address learn limiting • Quality of Service support with four traffic classes • QoS determined by Port, IEEE 802.1p tagged frames, IPv4’s Type of Service (TOS) &Differentiated Services (DS), IPv6’s Traffic Class802.1Q VID, Destination MAC address, or SourceMAC address • DSCP (layer 3) to frame priority (layer 2) marking • Frame priority overrides based on DA, SA, VID,Ethertype, BC, IP, PPPoE, ARP, or Snoop • Queue priority overrides based on DA, SA, VID,Ethertype, BC, IP, PPPoE, ARP, or Snoop• Strict, Weighted, or mixed mode QoS selectable perport • Globally Programmable QoS weighting via a128-entry table • 802.1Q VLAN support for the full 4,096 VLAN IDs • Supports multiple provider ports within a single chipvia a programmable Ethertype per port • Enhanced 802.1s Per VLAN Spanning Tree supporting up to 64 spanning tree instances • Single Link/Activity LED programmable across multiple ports - Single and Dual color LED support for Link,Speed, Duplex Mode, Collision, and Tx/Rx Activities Features • Single 3.3V supply • Marvell® Header for increased Routing performance • Shared 1 Mbit on-chip memory-based switch fabric with true non-blocking switching performance • High performance lookup engine with support for up to 8K unicast or multicast MAC address entries with automatic learning and aging • MAC SA based 802.1X authentication • Port Trunking and Port Monitoring/Mirroring • Egress tagging/untagging selectable per port or by802.1Q VLAN ID • Port based VLANs supported in any combination across multiple chips • Port States & BPDU handling for Spanning Tree • 28 32-bit and 2 64-bit RMON Counters per port • Egress Rate shaping on all ports • Ports 5 and 6 support RGMII/MII/RMII interfaces. Additionally, Port 6 also supports a GMII interface • Integrated with five independent Auto-Cross over Ethernet transceivers fully compliant with the applicable sections of IEEE802.3 and IEEE802.3u - Integrated MDI interface termination resistors - Integrated Advanced Virtual Cable Tester®(VCT™) cable diagnostic feature • Requires a low-cost 25 MHz XTAL clock source • Supports 4-Wire 93C56/93C66 or 2-Wire24C01/24C02/24C04 EEPROMs - Able to program attached EEPROMs and save configurations • 14 x 14mm 128-pin TQFP package • Low power dissipation PAVE = less than 2W Applications • Gigabit Ethernet broadband router with 4 1000Base-TX LAN ports and one 1000BASE-TX or 1000BASE-X WAN port • 5 port Gigabit Ethernet Switch TERMS & CONDITIONS If you choose to bid on this item, you are agreeing to the terms and conditions below: PAYMENT: · Please pay immediately after the auction has ended METHODS OF PAYMENT: · We accept PayPal only · We will wait for payment to be clear before shipping out your item. SHIPPING: · Your item is usually shipped within 3 business day at the latest. · We ship WORLDWIDE. RETURN POLICY: · The instrument has guarantee of 14 days * Sales Tax: All Buyers from Israel - Must add 17% VAT ("Ma'am")* Customs/Taxes/Duties: If your customs office/government charges additional taxes you are responsible for those. We have no way to know if, when or how much that will be. Please consult your local customs office or government for more information.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Marvell
MPN	MVL88E6172-A1-TFJ2C000
Model	MVL88E6172-A1-TFJ2C000
Country/Region of Manufacture	Taiwan
