Maxrad Pctel Z3136 16db Gps Timing Reference Antenna

US $56.95

Churchville, New York, United States
Jul 26th

Open on mobile:
QR code

MAXRAD PCTEL 16DB GPS TIMING REFERENCE ANTENNA W/ MOUNTING KIT - BRAND NEW NOTE - This unit does not include the original packing box, but it includes all pieces and documentation. ITEM DESCRIPTION: Maxrad PCTel Z3136, 16 dB Internal Amplifier The Z3136 timing reference antennas are specifi cally designed for long-lasting, trouble-free deployments in congested cell-site applications. Their 16 dB high gain amplifier is well suited to address attenuation issues associated with applications requiring longer cable runs. The proprietary quadrifiliar helix design, coupled with multistage filtering provides superior out-of-band rejection and improved elevation pattern performance than traditional patch antennas. Their unique radome shape sheds water and ice, while eliminating problems associated with bird perching. The antenna may be purchased by itself or with pipe mounting hardware. Custom models or site kits options are also available. This antenna is made of materials that fully comply with provisions stipulated by EU directives RoHS 2002/95/EC. Low Noise Amplifier Specifications Frequency Band: 1575.42 center frequency 3 dB bandwidth +/- 10 MHz Amplifier Gain: 16 dB +/- 3 dB Nominal Impedance: 50 Ohms Output VSWR: <2.0:1 Maximum Noise Figure: <= 2.5 dB at +25°C DC Voltage: 3.3 - 6.0 V (regulated) DC Current: 20 mA, 30 mA max at 5V Polarization: Right hand circular Filtering: 3 stage fi lters including pre-selector Out of band rejection: -60dB at 1575.42 +/- 50 MHz Electrical Specifications Frequency Band: 1575.42 +/- 10 MHz Antenna Element Gain: 4.5 dBic Nominal Impedance: 50 Ohms VSWR: <1.5:1 Polarization: Right hand circular Connector: Type N female Input/Output: ESD protected, Reverse polarity protection, Transient voltage suppression on output Mechanical Specifications Antenna Dimensions: 5” H x 3.2” D (126 mm H x 81 mm D) Shipping Dimension: 7.5” L x 4.4” W x 3.8” D (190 mm L X 112 mm W x 96 mm D) Antenna Mass: 0.6 lbs (0.3 kg) Shipping Mass: 1.9 lbs (0.9 kg) Radome Color: White Environmental Specifications Temperature Range: -40°C to +85°C Humidity: Up to 95% Mounting All mounting options fit pipes of 1” to 1.45” (25 mm - 37 mm) maximum diameter. Includes universal mounting hardware consisting of L-Bracket mount. Shipping See shipping calculator for shipping costs. Guarantee: The item above is guaranteed to be as described. All items are guaranteed against being DOA for 7 days after item is delivered. If you have any questions, please contact us via EBay's mail system. We want your purchase to be a satisfying experience! Payment: Only verified PayPal users with a confirmed shipping address will be accepted when paying with PayPal, otherwise your PayPal payment will be denied. Payment must be received with-in 7 business days of the end of the auction. We also accept checks, however, we will only ship the item when the check has cleared your bank. Shipping: Insurance is required on all items totaling more than $100.00. Inspect your item carefully when you receive it. If your item is damaged in transit bring it to the attention of the delivery person immediately or contact the shipper as soon as possible to fill out a claim for damages. Do not return damaged item to us as this will just delay the claim process and you may incur additional unnecessary shipping costs. Thank You. Returns: Returns accepted with-in 7 days after item is delivered. No returns accepted unless previously authorized and only if item description is deemed incorrect or misleading. Items returned must be insured, in original box with all contents included packing, manuals, accessories. Shipping and handling charges are not refundable. No returns on items sold as is.

Condition:	New – Open box: An item in excellent, new condition with no functional defects. The item may be missing original packaging and may have been used for testing or demo purposes. The item includes accessories found with the original product and may include a warranty. See the seller's listing for full details and description. ...	MPN	PCTel Z3136
Brand	MaxRad
