Maynuo M9710 Usb Programmable Dc Electronic Load 30a 150v150w Dc 245

US $280

china, China
Jun 17th

Open on mobile:
QR code

Note: There are two working voltage that powers the DC load: either 110V or 220V. Please make sure the right voltage setting has been selected manually for your area. You can set the voltage through the switch in the backside. Features: Features: Six high speed operation modes: CC,CR,CV,CW,CC+CV,CR+CW Over current, over voltage, over power, over heat, polarity reversed protection High-luminance VFD screen with two lines& four channels display Intelligent fan system fan will be automatically initiated according to the temperature Soft start time setting, carrying the power supplier according to the voltage value set Battery testing and short-circuit function Available of dynamic testing and rising edge and falling edge setting Supporting external trigger input and output External current waveform monitor terminal Supporting remote voltage compensation and multidata storage Power-on-self-test, software calibration and standard rack mount Communication mode: RS232/USB Application: Production line(cell phone charger, cell phone battery, electric vehicle battery, switching power supplier, linear power supplier), research institutes, automotive electronics, aeronautics and astronautics, ships, solar cells fuel cell, etc SPECIFICATIONS Model M9710 Input Rating Power 150W Current 0-30A Voltage 0-150V CC Mode Range 0-3A 0-30A Resolution 0.1mA 1mA Accuracy 0.03%+0.05%FS 0.03%+0.05%FS CV Mode Range 0.1-19.999V 0.1-150V Resolution 1mV 10mV Accuracy 0.03%+0.05%FS 0.03%+0.05%FS CR Mode Range 0.03-10K Oh 0.03-5K Oh Resolution 16 bit 16 bit Accuracy 0.1%+0.1%FS 0.1%+0.1%FS CW Mode Range 0-150W 0-150W Resolution 1mW 10mW Accuracy 0.2%+0.2%FS 0.2%+0.2%FS Voltage Measurement Voltage 0-19.999V 0-150V Resolution 1mV 10mV Accuracy 0.015%+0.05%FS 0.015%+0.05%FS Current Measurement Current 0-3A 0-30A Resolution 0.01mA 0.1mA Accuracy 0.05%+0.1%FS 0.05%+0.1%FS Power Measurement Power 100W 150W Resolution 1mW 10mW Accuracy 0.2%+0.2%FS 0.2%+0.2%FS Battery Test Battery Input: 0.5-120V; Max. Measurement: Capacity = 999AH; Resolution=0.1mA; Test Range=1S-32H Dynamic Test Transition List:0-5kHZ; ; T1&T2:60uS-999S; Accuracy:+15% offset+10%FS Current soft-startup Time 2mS;5mS;10mS;20mS;50mS;100mS;200mS;500mS;1000mS Accuracy:+15% offset+10%FS Short Circuit Current(CC) =3.3A =33A Voltage(CV) 0V Resistance(CR) =55mOh Temperature Operating 0~40oC Nonoperating -10oC~70oC Dimension W*H*D(mm) 214*108*365 Weight Kg 3.5 We only accept Paypal We usually use Economic shipping: will take about 11-20 days,if over 25days,still have not arrive,please contact us,will help you,please dont leave negative feedback or open case,we will try my best to satisfied with you! We accept return if items are not as described after recieved 5days,but buyer need pay ship cost,please make good package,thanks your help! Thanks your business,Have a great day!!! Patriciad3120 Prohibited Duplication © 2010 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
