MC MACHINERY SYSTEMS LT-520 CNC LATHE, Mit, 3" Bar, 10" Chk, 10 Tools, (2015), US $520 – Picture 0
MC MACHINERY SYSTEMS LT-520 CNC LATHE, Mit, 3" Bar, 10" Chk, 10 Tools, (2015), US $520 – Picture 0

Mc Machinery Systems Lt-520 Cnc Lathe, Mit, 3" Bar, 10" Chk, 10 Tools, (2015)

US $520

  • Waxhaw, North Carolina, United States
  • Jun 1st
Open on mobile:
QR code
Charlotte, NC (803)548-8000 Chicago, IL (630)584-8885 2015 MC MACHINERY SYSTEMS LT-520     Chuck Size 10"   Max Diameter Bar Capacity 3.07"   Max Swing Over Bed / Carriage 20.47" / 15.75"   Turning Diameter (Max / Std) 15.75" / 11.3"   Distance Between Centers 33.27"   Max Machining Length 27.95"   Spindle Speed 30 - 3500 RPM   Spindle Bore 3.5"   Spindle Nose A2-8   Spindle Motor 25 HP   Tools 10   Rapid Traverse Rates (X & Z) 794 IPM   X-Axis Travel 8.66"   Z-Axis Travel 27.95"   Tailstock Taper MT#5   Machine Dimensions (L x W x H) 112.2" x 70.9" x 74.6"   Machine Weight 11,023 lbs.         FEATURES:   MITSUBISHI M70V CNC CONTROL   10.4" Color LCD   64-Bit Risc Processor   10" 3-Jaw Hydraulic Chuck   Tool Presetter   Key Arrow Chip Conveyor (Side Exit)   Servo Driven Turret   Three Color Tower Light   Chip Bucket   Mfg Date August 2014   Installed in January 2015
