McLaughlin Verifier G2 Digital Electronic Service Utility Locator . PC, US $4800 – Picture 0
McLaughlin Verifier G2 Digital Electronic Service Utility Locator . PC, US $4800 – Picture 0

Mclaughlin Verifier G2 Digital Electronic Service Utility Locator . Pc

US $4800

  • Victoria Point, QLD, Australia
  • May 27th
Open on mobile:
QR code
McLaughlin Verifier G2 Digital Electronic Service Utility Locator.   Perfect Condition. SPECIFICATIONS Receiver Specifications Active Frequencies 38kHz: 38kHz±2% 9.5kHz: 9.5kHz±2% 80kHz: 78.125kHz±2% 512kHz: 512kHz±2% Passive Radio Radio: 9k to 33kHz Passive Power 50/60Hz: 5th harmonic (50Hz or 60Hz user selectable) 100/120Hz: 3rd harmonic (100Hz or 120Hz user selectable Battery Type 8 Alkaline LR6 “AA” Battery Life 20 hours Battery Status Continuous indication Power Save Function Automatically power off after 5 minutes of inactivity Visual Indication LCD: Bar graph, digital number and character, include backlight Depth Range Line: 0 to 5m/16ft (0-5m/0-16ft. mode) 0 to 10m/30ft (0-5m/0-30ft. mode) Probe: 0 to 10m/30ft. Depth Readout Unit Meter/ft. & inch Depth Accuracy* 2.0m/6.5ft: ±2.5% 3.0m/10ft: ±5% 5.0m/16.5ft: ±10% Current Value Current value flowing on the conductor is displayed for line identity in milli-amps Audio Output Internal speaker (200 to 5kHz), Earphone (optional) Data Logging Memorized 400 points of the depth/current measurement data Interface D-sub 9-pin connector (RS-232C) Operating Temperature -20°C to 50°C/-4°F to 122F° Dimensions 680x140x290mm (26.8”x5.5”x11.4”) Weight 2.1kg/4.7lbs approx. including eight batteries Notes *1—locators are tested in the model field conditions with no adjacent signals. Always excavate the line with non-destructive means before digging *2—Optional cable is necessary to read the logging data Transmitter Specifications Output Frequencies 38kHz: 38kHz±0.02% 9.5kHz: 9.5kHz±0.02% 80kHz: 78.125±0.02% 512kHz: 9.5kHz/38kHz±0.02% Output Power 5 watts max. /80kHz: 1 watts max. Battery Type Eight alkaline LR20 “D” Battery Life Direct mode: 50 hours (output 4mA, 20°C/68°F) Battery Status Low battery indication and press key readout Visual Indication LCD: bar graph & digital number, includes backlight Audio Indication Internal speaker: alarm, beeping sounds Measuring Function Output current: 0 to 300mA Line voltage: 0 to 250V Output Protection AC 250V (512Hz: output is cut off automatically) Operating Temperature -20°C to 50°C/-4°F to 122F° Dimensions 275x314x110mm (10.8”x12.4”x4.3”) Weight 3.7kg/8.2lbs approx. including eight batteries
