Mcpherson Controls Advr-12 12 Amp Universal Automatic Digital Voltage Regulator

US $2300

Forest Grove, Oregon, United States
Jun 20th

Open on mobile:
QR code

McPherson Controls MTS ADVR-12 12 Amp Universal Automatic Digital Voltage Regulator Use on CAT Gen with PMG, and Shunt. The ADVR-12 is a totally new hybrid 12 Amp universal voltage regulator with a comparable footprint as the Basler* AVC63-12 and AVC125-10, CAT* VR6, KATO* K65-12B and K125-10B, and the Leroy Somer* 202-8634, and many other. To simplify installation, voltage sensing without PT’s up to 520 volts was added, also new DIP & TRIM adjustment compatible with many automatic paralleling and PF controllers in the market. The new CPU design makes the ADVR-12 exceedingly stable, however keeping the analog power circuit for fast response. Single Phase or Three Phase Sensing & Power Input Voltage Regulation < ±0.5% 220/380/440/480VAC Programmable Input IP Switch Selectable 50/60Hz Multiple Excitation System Compatibility: SHUNT, AU X, PMG Inverse-time Over Excitation Protection Under Frequency Protection Soft Start Voltage Ramping EMI Suppression Built-in High Capacity Protection Fuse The ADVR-12 12 Amp Universal Automatic / Digital Voltage Regulator is a Compatible Replacement for the Caterpillar 3516 - VR6 - VR3 - CDVR - K125-10B - K65-12B Basler Digital AEC63-7 - AVC63-12A - 1DBT63-7 - DECS-100-B15 - DECS-200-2L - Digital DM110 - KR4FF. GEC ALSTHOM C10 / 120 - DX21. COSIMAT N/N3 14392/04.92. Marathon DVR2000 - DVR2000E - PM100 - PM200 - PM300. ABB 1000-7 - EA63-5 - GX300. Sensing Input Voltage 180~520VAC single phase or three phase DIP switch selectable Frequency 50/60Hz jumper selectable Power Input Voltage 100~300VAC single phase or three phase Output Voltage Max. 125VDC @ 220VAC Current Continuous 12A Intermittent 25A for 10 sec. Volts Regulation < ±0.5% (with 4% engine governing) Voltage Build-up Residual volts at AVR terminal > 6 VAC Over Excitation Protection Inverse-time 125 ± 5VDC @ 220VAC External Volts Adjustment 10 K Ohms 1 watt trimmer Unit Power Dissipation Max. 8 watt Soft Start Ramp Time 4 sec. EMI Suppression Internal electromagnetic interference filtering Thermal Drift 0.03% per Degree C change in AVR ambient Under Frequency Protection (Factory Knee Point Setting) 60Hz system presets knee point at 55Hz/50Hz system presets knee point at 45Hz We are an Authorized Dealer and Retailer for GAC, Kohler, Generac, Onan Cummins, Ronk Electrical, Deep Sea Electronics, Stamford Winco, Thomson Power Systems, Aksa and many more. We strive for 100% customer satisfaction for parts and service. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
