Measurement Computing Usb-1208ls 8 Channel 12 Bit Input

US $84.00

Hallandale, Florida, United States
Jan 29th

Open on mobile:
QR code

This is a brand new device. The device is in unopened anti static bag, it comes with all softwares Data Acquisition Software CD UL for Labview CD Universal Library CD It also come with a DAQ Software quick Start book a User's guide and a USB cable. USB-1208LS USB-based 8 Channel Data Acquisition Device Measurement Computing USB-based 8 Channel 1.2 kHz Data Acquisition Device The USB-1208LS from Measurement Computing is a low speed USB device that features 8 analog inputs, 2 10-bit analog outputs, 16 digital I/O connections, and 1 32-bit external event counter. The USB-1208LS analog inputs are software configurable for either 8 11-bit single-ended inputs, or 4 12-bit differential inputs. An on-board industry standard 82C55 programmable peripheral interface chip provides the 16 digital I/O lines in 2 8-bit ports. You can configure each digital port independently for either input or output. The USB-1208LS is powered by the USB port on your computer. No external power is required. USB 8 Channel DAQ includes: >> 2 Meter Long USB Cable >> Measurement Computing’s DAQ software suite that includes TracerDAQ, The Universal Library, Comprehensive drivers for DASYLab and NI LabVIEW as well as InstaCal software utility for installation, calibration, and testing. 8 Analog Input DAQ Module Specifications A/D Converters Successive Approximation Type Sampling Rate Up to 50 kS/s Maximum. 2 Channels: 25 kS/s 4 Channels: 12.5 kS/s Number of Channels 8 Single Ended / 4 differential, software selectable Input Ranges Single Ended Mode ±10V, G=2 Differential Mode ±20V, G=1 ±10V, G=2 ±5V, G=4 ±4V, G=5 ±2.5V, G=8 ±2.0V, G=10 ±1.25V, G=16 ±1.0V, G=20 Software Selectable Input Voltage Range (Linear Operation) Single Ended Mode: ±10 Volts Max Differential Mode: -10 Volts Min; +20 Volts Max Resolution Differential: 12 Bits, no missing codes Single Ended: 11 Bits Memory Non-Volatile with 1024 bytes Storage Power Source USB Port, No External Power Connection USB Device Type: USB 1.1 low-speed Compatibility: USB 1.1 and USB 2.0 Cable Length: 3 Meters Maximum Operating Range Temperature: -0° to 70 °C Humidity: 0 to 90% RH Non-Condensing Storage Range Temperature: -40° to 70 °C Humidity: 0 to 90% RH Non-Condensing OS Compatibility Windows 7, Vista, XP SP2+ (32-Bit or 64-Bit) Dimensions 79mm x 82mm x 25mm

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Measurement Computing
Model	USB-1208LS
