Megatorque Motor Kit, Motor/controller

US $2,000.00

Charlotte, North Carolina, United States
Jan 29th

Open on mobile:
QR code

M-YSB5120KN002 motor M-ESB-YSB5120AB500 controller Motor Information:Torque up to 120Nm (1062 inlb) RPM up to 180 (see chart in PDF catalog for performance) Absolute position feedback @ 819200 PPR 19,600N maximum axial load, 400Nm moment max Repeatability +/- 1.5 Sec Heavy duty metal power & feedback connectors Controller Information:Controllable via I/O, pulse & direction, analog Power Requirements, 230VAC motor & 24VDC control Digital I/O (20/9), inputs PNP or NPN Programs via Hyper Terminal Direct Drive The Megatorque Motor is drivew the load directly without using a mechanical speed reducer, and as a result, it achieves highly accurate positioning without backlash and lost motion. A Megatorque Motor is a servomotor that equips a position detector to form full closed loop control. High Accuracy The YSB Series Megatorque Motor incorporates a high-resolution position detector (resolver) that features 819 200 pulses/revolution. This contributes to an exceptionally precise repeatability of ±1.6 arc seconds. High Reliability The Megatorque Motor is a brushless motor and does not use permanent magnets in its simple construction. It is equipped with a highly rigid and accurate roller bearing (crossed roller bearing), which is packed with lubrication grease, thus offering highly reliable and long-term maintenance-free operation. Highly Functional Driver Unit The YSB Series Megatorque Motor works in combination with an ESB Driver Unit for a digital servo control incorporating a 32-bit microprocessor. The ESB Driver Unit has a number of command inputs necessary for motion control, thus permitting its connection with sequencers, a variety of positioning controllers and personal computers, etc. In addition, acceleration profiling and networking functions through various field buses are available. Includes Absolute Position Detector as Standard Equipment The YSB Series Megatorque Motor has an absolute position detector as standard equipment. This contributes to eliminate the troublesome Homing and thus improves productivity. Additionally, the motors and the driver units can be randomly matched. Cable are available in lengths up to 30m. Conformity to the International Safety Regulations The Megatorque Motor systems conform to the EC Directives (CE Marking) and Underwriters’ Laboratory (UL) regulations.
