Melles Griot Nanomax Ts Xyz 17max301 Stage W/ 3 17drv001 Actuators / Thorlabs

US $330

Laguna Niguel, California, United States
Jun 21st

Open on mobile:
QR code

Melles Griot 17MAX301 three Axis XYZ Parallel Flexure Stage with three 17DRV001 Stepper Motor Drivers, and 3 controller to motor cables. The stage is compatible with the ThorLabs MAX301. Features: X, Y, Z Motorized travel: 4mm Each of the three axes has a built-in piezo actuator with feedback, input: 0 - 75V, damage threshold: 100V. Piezo Actuator Travel ( X, Y, and Z ): 20 um Piezo drive / feedback electronics are NOT included The three 17DRV001 actuators have high precision lead screws and may be driven by almost any 4 wire stepper drive. Actuator drive electronics are NOT included. Stage Dimensions, without actuators: 112 mm W x 112 mm L x 62.5 mm H Stage Dimensions, including actuators (with stages extended): 212 mm W x 215 mm L x 64.5 mm H Mounting Platform Dimensions: 118mm x 118mm Mounting platform hole pattern: 17 x M6x1.0, 4 x M4, and 4 x M3 Load Capacity: 1 kg Includes three drive electronics to motor cables. These extension cables may not work, without modification, with the drivers you select. There's a Melles Controller to Computer cable, visible in the 4th photo, that WILL NOT be included as it doesn't connect to anything in this sale. XYZ Stage with actuators and cables about 9 kg, packed for safe shipping. ThorLabs Data Sheets Stage: http://www.thorlabs.us/thorcat/10900/MAX301-Manual.pdf Melles-Griot Catalog Pages for NanoMax300-TS Series Stages Catalog Page: http://kik.creol.ucf.edu/documents/17max300specs.pdf Only the items shown in the photos or listed in the description are included. Guaranteed fully functional as originally designed and shipped. __________________________________________________________________________________________________________ If you have any questions or concerns please make them known before bidding. PayPal only for domestic buyers ( except when local pick-up is offered ). FedEx will require a direct adult signature to release this package. For local pick-up in Orange County, CA:: Since proof of delivery can't be established to meet eBay and PayPal standards, should a delivery dispute arise, I require cash only for local pick-ups. Don't use PayPal if you intend to pick up this item, Delivery fees will be waived if you pick this equipment up. We're about midway between downtown Los Angeles and downtown San Diego. California sales tax ( 8.00% ) will be added for CA deliveries unless your valid resale certificate is provided prior to checkout ( this includes local pick-ups, even if you're from out of state ). __________________________________________________________________________________________________________ ATTENTION INTERNATIONAL BIDDERS: Contact me prior to bidding if you're concerned with the eBay calculated shipping rate. I can often do better. Considering the size and weight of this package it's going to be quite expensive to ship in any case. Shipping by US Postal Service Express Mail International because no other USPS option allows the parcel to be fully insured. Insurance will add US$ 30 - 40 to the shipping cost. Payment by PayPal or wire transfer. Import or brokerage fees, duties, or other taxes or levies are your responsibility as the buyer. They are not included in the item's sale price or the shipping cost.
