Memcor Kearfott Insulated Variable Resistor 250 Ohm 300v .53-1.0 Amp R-100 New

US $23.28

Westerville, Ohio, United States
Feb 27th

Open on mobile:
QR code

FOR SALE IS A BRAND NEW MEMCOR TYPE R-100 VARIABLE RESISTOR.THE NSN NUMBER IS 5905-00-243-1330.HERE ARE THE SPECS: AAPN Section Quantity 1 AAQL Body Style Cylindrical bushing mounted AARG Reliability Indicator Not established ABPM Body Diameter 3.125 inches nominal ABWV Shaft Diameter 0.188 inches nominal ABXF Shaft Length 0.875 inches nominal ADAP Mounting Bushing Length 0.375 inches nominal ADAQ Body Length 1.719 inches nominal AEDX Shaft Style Round AEFD Actuator Type Single shaft AEFH Effective Electrical Rotation IN DEG Angular Rotation 295.0 nominal AEFN Nonturn Device Location At 9 oclock AEFP Nonturn Device Radius 0.531 inches nominal AJYN Screw Thread Diameter 0.375 inches nominal AJYP Screw Thread Series Designator UNEF AJYQ Screw Thread Quantity PER Inch 32.0 APXH Terminal Location Radially positioned over less than half the circumference AXGY Mounting Method Standard bushing CQCC Electrical Resistance PER Section 250.0 ohms single section CQCK Rotary Actuator Travel IN Angular DEG 295.0 nominal CQGN Ambient Temp IN DEG Celsius PER Section AT Zero Percent Rated Power 120.0 single section CRGD Power Dissipation Rating PER Section IN Watts 100.0 free air single section CRSS Resistance Tolerance PER Section IN Percent -10.0/+10.0 single section CRSX Actuator Travel Control Feature Stops CSDH Ambient Temp IN DEG Celsius PER Section AT Full Rated Power 70.0 single section CSDL Standard Taper Curve PER Section A single section TTQY Terminal Type AND Quantity 3 tab, solder lug .IF YOU HAVE ANY QUESTIONS,PLEASE FEEL FREE TO CALL ME 1-614-580-0951.You will not be disappointed.My feedback speaks for itself.If you have any questions please email me and please check out the other items i have for sale.If you have problems with your order,PLEASE CONTACT ME BEFORE LEAVING FEEDBACK.Thanks,mark ATTENTION ATTENTION /NOTICE NOTICE!!! BEFORE LEAVING FEEDBACK PLEASE PLEASE PLEASE CONTACT ME.I WANT TO MAKE YOU HAPPY AND FIX THE ISSUE.IF YOU BOUGHT THE WRONG THING,IT IS BROKEN,IF SHIPPING TOOK TO LONG OR EVEN IF YOUR HAVING A BAD DAY.I WANT TO HELP!!I WANT TO KEEP MY FEEDBACK CLEAN .

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	MEMCOR
Model	R-100
