Merrimac CTM-20M-1.25G Directional Coupler 20 db, 50 W, US $65.00 – Picture 0
Merrimac CTM-20M-1.25G Directional Coupler 20 db, 50 W, US $65.00 – Picture 0

Merrimac Ctm-20m-1.25g Directional Coupler 20 Db, 50 W

US $65.00

  • Laguna Hills, California, United States
  • Jan 29th
Open on mobile:
QR code
  Merrimac CTM-20M-1.25G Directional Coupler 20 db, 50 W   Description 1. The CTM series directional couplers are miniature three port devices utilizing stripline technology in a connectorized package. Each is a multi-section quarter wave coupler designed to cover a broad bandwidth. They are ideally suited to monitor forward or reflected power with minimal perturbation to the main line signal, signal sampling, control loops and test signal injection devices in BITE. 2. A variety of models may be custom ordered with coupling values up to 30 dB and covering frequency bands up to 18 GHz. 3. These units comply with MIL-C-15370 and may be supplied screened for compliance with additional specifications you designate for military and space applications requiring the highest reliability Key Features & Specifications Frequency Range 500.00 to 2000.00 MHz Insertion Loss 0.35 dB VSWR 1.20 :1 Sold as pictured, no additional software, manuals or accessories provided. Email  your questions to sales@gstestequipment.com   CA residents add 8% CA State Sales Tax.     We buy your excess test equipment. Please contact sales@gstestequipment.com or call (949) 679-5561
Condition:
Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...
Brand Merrimac
Model CTM-20M-1.25G
