Mesr-100 Esr Capacitance Ohm Capacitor Meter Resistance Circuit Tester+smd P4e0

US $55.35

Dayton, New Jersey, United States
Sep 1st

Open on mobile:
QR code

This MESR-100 V2 auto-ranging capacitor ESR and low Ohm meter measuring range from 0.001 to 100.0R, support in circuit testing. Using true 100 KHz sine wave to measure the ESR value, which is equal to the testing method of capacitor manufacturer. Features: It is a series resistor inside capacitor, using 100kHz to remove the impedance 1/(2*pi*F*C). The impedance become small, and we can then measure the true series resistor value. Using this theory, we can measure the capacitor is bad/ damaged or good in condition. Our ESR meter only applies less than 15mV DC or peak to peak on a good capacitor, as a result we can use it as in circuit test. During repairing TV, LCD, Audio board, etc. we can in circuit testing the capacitor is good or not. Dual terminal, for fast and easy inspect internal resistance of the capacitor, a printed ESR table for fast check. Equipped with a SMD alligator clip for more accurately testing. Copper plating on the surface, which is anti-corrosion and oxidation resistance. Specifications: Color: Black Range Accuracy(After zero, Refresh Time(Manual Mode) tested with 1,10,100R Auto mode take 0 to 2s, more time resistor) depends on capacitance value. 0.000 to 1.000R 1%+2Digit 0.4s 1.000 to 10.00R 1%+1Digit 0.4s 10.00 to 100.0R 2%+1Digit 0.4s Accuracy: Up to 1% (detail on above table) Wide Measurement Range: >1uF High Resolution: 4 digit, or 0.001Ohm @ 1 range Measuring voltage: <40mV RMS (TESTING VOLTAGE) External Power: 5V micro USB Operating Current: 0.02A Battery: 2 * AA 1.5V Battery (not included) Battery Life time: >80 Hours Item Size: Approx 14.5 * 8 * 3cm / 5.7 * 3.1 * 1.2in Item Weight: Approx 139.6g / 4.9oz Package Size: Approx 17 * 9 * 5cm / 6.7 * 3.5 * 2.0in Package Weight: Approx 218g / 7.7oz Package List: 1 * Capacitance Meter 2 * Test Clips 1 * SMD Clip 1 * User Manual Note: The Capacitance Meter is used for testing the internal resistance of the capacitor, not for testing capacitance value.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	External Power	5V micro USB
Battery Life time	>80 Hours
Item Size	Approx 14.5 * 8 * 3cm / 5.7 * 3.1 * 1.2in
Battery	2 * AA 1.5V Battery (not included)
Color	Black
Measuring voltage	<40mV RMS (TESTING VOLTAGE)
ASIN	B08W5637LN
Package Weight	Approx 218g / 7.7oz
MPN	Does not Apply
Operating Current	0.02A
High Resolution	4 digit, or 0.001Ohm @ 1 r-ange
Item Weight	Approx 139.6g / 4.9oz
Brand	Unbranded/Generic
Wide Measurement R-ange	>1uF
Accuracy	Up to 1% (detail on above table)
Package Size	Approx 17 * 9 * 5cm / 6.7 * 3.5 * 2.0in
Type	Ohm Meter
