Mesr-100 Professional Autoranging In Circuit Esr Capacitor Low Ohm Meter Tester

US $49.99

Shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

template MESR-100 Professional AutoRanging In Circuit ESR Capacitor low ohm Meter Tester New Specification: Measuring range from 0.001 to 100.0R, support IN CIRCUIT Testing. Accuracy: Up to 1% (detail on above table) Wide Measurement Range: >1uF (for 0.1uF the error will be larger on equation 1/(2*pi*F*C) @ 100Khz ) High Resolution: 4 digit, or 0.001Ohm @ 1 Ohm range Measuring voltage: <~40mV RMS (TESTING VOLTAGE) Clamping voltage: ~0.15V (open voltage) Battery 2X AA 1.5V battery External Power: 5V micro USB Operating current 0.02A Battery Life time: >80 Hours Range Accuracy (After Zero, tested with 1,10,100R resistor) Refresh Time (Manual Mode) *Auto mode take 0 to 2s more time depend on value 0.000 to 1.000R 1%+2Digit ~0.4s 1.000 to 10.00R 1%+1Digit ~0.4s 10.00 to 100.0R 2%+1Digit ~0.4s How to operation it: 1) POWER ON Press and hold the ON/ OFF circle orange button for 2 to 3 second to power on. Press and release the ON/ OFF button to shut down meter. 2) AUTO/ MANUAL mode: i) Auto Range: Press and release the RANGE button and at the first line of LCD will show “AUTO:" At auto mode meter will automatically select the best range to detect. ii) Manual Range: Scroll the manual range from 1R, 10R and 100R range by press and release the RANGE button In LCD will show MANUAL at first LCD line and show at second line: 0-1R, 1-10R and 10-100R. 3) 1 Key Zero: Short circuit the test leads’ terminal, cancelling the wire resistance. Press and release the “ZERO" button, LCD shows “ZERO" and wait the zero disappear. If you are using the meter array socket, you need to use a short pin to short circuit to set zero. 4) Backlight: LCD backlight will on during power on 5) Auto Sleep: Around 10 hours for not testing, it will shut down automatically to save power. 6) OVERFLOW or OL: Display overflow when the value is out of range, you can check that you are zero correctly. 7) ESR TABLE: It is for reference only, different manufacturer of capacitor has different ESR, better to test a good cap ESR and compare with what you are testing, usually bad cap with higher ESR few times larger than good one. 8) SOFTWARE ESR: Put the 25V Electrolytic capacitor value to LCD, and compare, GOOD if C < XXuF, means the capacitor maybe good condition if it is less than XXuF 9) PLASTIC STAND: If you don’t use the stand, press and push the lock position: What in Package: 1 X MESR-100 V2 2 X 15cm test clips (as picture) 1.Your valid phone number is very necessary for the shipping, otherwise we can't guarantee that the package would safely arrives. 2. Any Customs tax applied to this package should be covered by buyers. Payment 1. Payment methods accepted : Paypal only. 2. Payment must be received within 7 business days of auction closing. Shipping 1. We ship your orders within 1-2 business days after the payment received. 2. Item shipped via Singapore Post or HongKong Post , It takes about 7-14 business days (USA,CA,AU,UK).others country 10-20 business days(Brzil,India,RU),Exact delivery time depends on postal process. 3. If you do not receive your item(s) by 30 business days,Please feel free to contact us via ebay mail system , we will try our very best to resolve any problems with you Return Policy 1. Return is accepted within 14 days after the buyer's receiving the item. 2. If this item is defective upon receipt, customer has up to 14 days from date of receipt for exchange of a new one. 3. Unused/unopened merchandise will be fully credited. Other Policies We are not responsible for any custom duty or import tax. If you need we write low price on shipping bill, pls leave message when you make payment . All emails will be answered within 24 hours. If you do not receive our reply, please kindly re-sent your email and we will reply to you as soon as possible, Suggest send eBay message to us, That is easy to find .
