Meter Roughmeter Srt-6210 Rs232c Portable Surface Roughness Tester Ra/rz/rq/rt

US $130

  • Shanghai, China
  • Jan 29th
METER RS232C SURFACE ROUGHNESS TESTER ROUGHMETER RA/RZ/RQ/RT PORTABLE SRT-6210 NEW TESTER ACOUSTICS WELL/PRIT DEPTH METER MEASURE HANDHELD GAUGE MEASUREMENT SPEED ROTATE MACHINE AUTOMOBILE ENGINE GED2600P LASER MOTOR TESTER TACHOMETER SURFACE INTERFACIAL TENSIOMETER TENSION METER PLATINUM PLATE METHOD AUTOMATIC CEM FC-33 TESTER METER DMM 80A AC NEW IN BOX CLAMP CLAMP-TABLE DC TOOLS GAUGE This instrument is compatible with four standards of site to measure surface roughness of various machinery-processed parts, calculate corresponding and clearly display all measurement parameters. When measuring the roughness of a surface, the sensor is placed on the surface and then uniformly slides along the surface by driving the mechanism by the sharp built-in probe. This roughness causes displacement of the probe which results in change of inductive amount of induction coils so as to generate analogue signal, which is in proportion to the surface roughness at output end of phase-sensitive rectifier. The exclusive DSP processes and calculates and then outputs the measurement results on LCD. Metric /Imperial Conversion. Highly sophisticated inductance sensor. Small in size, light in weight and easy to use. Multiple parameter measurement: Ra, Rz, Rq, Rt. Four wave filtering methods : RC, PC-RC, GAUSS and D-P. Built-in lithium ion rechargeable battery and control circuit with high capacity. The tester can memorize 7 groups of measurement results and measuring conditions for later use or download to PC. Can communicate with PC computer for statistics, printing and analyzing by the optional cable and the software for RS232C interface. Manual or automatic shutdown. The tester can be switched off by pressing the Power key at any time. On the other hand, the tester will power itself off about 5 minutes after the last key operation. Function: Display 4 digits, 10 mm LCD, with blue backlight Parameters Ra, Rz, Rq, Rt Measuring Range Ra, Rq: 0.005-16.00um/0.020-629.9uinch Rz, Rt: 0.020-160.0um/0.078-6299uinch Accuracy Not more than 10% Fluctuation of display value Not more than 6% Sensor Test Principle: Inductance type Radius of Probe Pin: 5um Material of Probe Pin: Diamond Dynamo-measurement of Probe: 4mN(0.4gf) Probe Angle: 90 Vertical Radius of Guiding Head: 48mm Maximum driving stroke 17.5mm/0.7inch Cutoff length (l) 0.25mm/0.8mm/2.5mm optional Evaluation length 5l Driving speed sampling length = 0.25mm Vt=0.135mm/s sampling length = 0.8mm Vt=0.5mm/s sampling length = 2.5mm Vt=1mm/s returning Vt=1mm/s Profile digital filter Filtered Profile: RC Filtered Profile: PC-RC Filtered Profile: Gauss Non-Filtered Profile: D-P Resolution 0.001um: reading <10um 0.01um: reading >10um & <100um 0.1um reading > 100um Evaluation length 5 cut-off Power Li-ion Battery Rechargeable Operating conditions Temp. 0~50°C Humidity <80% Size 140x57x48 mm Weight 400g Package Include: 1xMain Unit 1xCarrying case 1xStandard Sensor 1xStandard Sample Plate 1xPower Adapter 1xOperation Manual 1xScrewdriver 1xAdjustable Leg 1xSensor Protector ilojyoi sijpidk emuknjt MPI Buyer should pay within 7 days after purchase. We only accept payment via PayPal. Our team focuses on providing high quality products with reasonable price and tries its best to keep transactions as simple as possible. Please be confident of and enjoy your shopping here! Please feel free to contact us via eBay message system or email.
