Mhs-5200a Digital Dds Dual-channel Signal Generator Source Frequency Meter

US $77.09

Shenzhen, China
Aug 14th

Open on mobile:
QR code

Description: Using DDS direct digital synthesis technology to produce accurate, stable, low-distortion output signal; CH1 and CH2 two channels completely symmetrical, each channel parameters can be set independently. Support user-defined waveforms, each set of arbitrary wave storage depth of 2048 * 12bits, 250MSa / s sampling rate; Waveform generator up to 12 bits wide, the output waveform is more delicate, the waveform distortion is reduced order of magnitude The NC includes a function to display and adjust the digital phase current output signal amplitude, offset, frequency, duty cycle and the two signals FSK keying and ASK amplitude keying signal output function; Instrument connection with the computer, the computer may be used by various functions and parameters PC control signal generator, and the instrument can be downloaded to the arbitrary waveform output waveform editing on a computer Communication function: Serial communication, the agreement is completely open, user-friendly secondary development Frequency accuracy: Frequency accuracy can reach 10-6 orders of magnitude High frequency resolution: the full range of frequency resolution 10mHz Tracking: Built-in frequency, amplitude, bias, duty cycle, waveform and other parameters to follow the function, easy to use Specification: Material: Plastic Color: White Size( LxWxH): Approx. 200x 180x 90mm/ 7.87x 7.09x 3.54inch Plug Type: US Plug Sine Wave:Normal Modes: 0Hz~6MHz Square Wave: 0Hz~6MHz Triangle Wave: 0Hz~6MHz Sawtooth Wave: 0Hz~6MHz Arbitrary Waveform: 0Hz~6MHz TTL Digital Signal Wave: 0Hz~6MHz Output Modulation: Frequency Sweep Waveform Types: Sine/Triangle/Square/Lifting Sawtooth Wave, CMOS Digital Signal Wave and Arbitrary Waveform Waveform Length: 1024Points Sampling Rate: 200MSa/s Waveform Amplitude Resolution: 8 Bits The Min. Frequency Resolution: 10mHz Frequency Error: +/-5*10^(-6) Frequency Stability: +/-1*10^(-6) Amplitude Range(Peak to Peak): 15mVp-p~15Vp-p(12MHz or Less), 15mVp-p~8Vp-p(12MHz and above) Output Impedance: 50(+/-10%) Amplitude Resolution: 1mVp-p (-20dB Attenuation), 10mVp-p (No Attenuation) Offset Range: -120%~120% (The ratio of bias voltage and signal amplitude) Bias Resolution: 1% Phase Range: 0~359° Phase Resolution: 1° Sine Wave Harmonic Arrived System: 40dBc(<1MHz); 35dBc(1MHz~20MHz) Distortion:<0.8%(20Hz~20KHz) Square Wave Lifting Along Time: 20ns Overshoot: 10% Duty Cycle Adjustment Range: 0%~99.9% TTL Lifting Along Time: 20ns Low Level:<0.3V High Level: 1V~7.5V Arbitrary Waveform Quantity: 16 Memory Depth/Group: 1KB/16 Scan Scan Mode: Linear Sweep, Log Sweep Scan Time: 1s-500s Scan Range: It is determined by the sweep parameter settings Memory Quantity:10 Location: M0~M9 Interface Interface Mode: using USB to Serial Interface Communication Rate: 57600bps Protocol :Using the Line, the Agreement Public Power Supply: DC ]MHS3200A DC 5V Power Supply External Measurements Frequency Measuring Range GATE-TIME=10S 0.1Hz - 60MHz GATE-TIME=1S 1Hz - 60MHz GATE-TIME=0.1S 10Hz - 60MHz GATE-TIME=0.01S 100Hz - 60MHz Input Voltage Range: 0.5Vp-p~20Vp-p Counting Range: 0~4294967295 Counting: Manually Positive and Negative Pulse Width Measurement: 10ns Resolution, the Max. Measurable 10s Periodic Measurement: 20ns Resolution, the Max. Measurable 20s Duty Cycle Measurement : 0.1% Resolution, Measuring Range from 0.1%~99.9% Source Selection: 1. Ext. IN Input(AC Signal) ; 2. TTL-IN Input(Digital Signal) Package Includes: 1 piece signal generator host 1 piece power cord 1 piece USB data cable 1 piece two channel clip line 1 piece data disc SKU: MST0017899160009743 Shipping And Handling Policy People always bought together with

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
Bundle Listing	No
Color	White
Country/Region of Manufacture	China
Designer/Brand	Unbranded
MPN	Does Not Apply
Manufacturer Part Number	Does not apply
Size	as described
UPC	Does not apply
ISBN	Does not apply
EAN	Does not apply
