Micro Controle Ue-71 Pp Motorized Xy Stages

US $965.00

Phoenix, Arizona, United States
Jan 30th

Open on mobile:
QR code

Fiber Optic Tools and Supplies BUY | SELL | TRADE ebay@surpluseq.com Contact Us Payment Shipping Description Micro Controle UE-71 PP Motorized XY Stages Used Micro Controle UE-71 PP Motorized XY Stages Model/Part No :UE-71 PP Our Item ID : 251578 Description Specific Details: Micro-Controle UE-71 PP Motorized XY Stages 20mm travel This unit made by Micro-Controle is a motorized XY translation stage. The stages are Newport model numbers B89-39588-002 and B93-82286-002. Unit is in excellent shape and can be used manually. Condition: Product Type: Used Terms of sales: Contact Us for Warranty Details Physical Condition: Good Working Condition: Good 18.00 | 16.00 x 16.00 x 10.00 | 0 Manufacturer"s Product Information: Description: The UE-71-20-PP Linear Stage incorporates many of the advantages of the popularUTM series providing superior motion performance in an enhanced, shorter, andlower profile package. It uses the same optimized steel body, bearings and leadscrew of the UTM stages, but features a number of mechanical improvements and a completely new motor configuration. The UE-71-20-PP is a cost-effective solution forless demanding applications. When used with our XPS, ESP300, or SMC100PPcontrollers with high micro-stepping capability, low-noise operation and verysmall incremental motions over the 20 mm travel range are guaranteed. Thestepper motor versions do not use encoders, instead, position is attained by thenumber of commanded steps and micro-steps. The stepper motor is directlyattached to the lead screw with a proprietary bellow coupling with high-torsionstiffness and no gear or belt drive in between. The high output torque of thestepper motor also minimizes the risk of lost steps and provides optimum motionsensitivity with good linearity between commanded micro-steps and the actualmotion of the stage. It features all-steel construction with preloaded linearball bearing slides. Smooth motion is provided by a diamond-corrected lead screwand a matched, precision lapped nut to ensure high position stability with highvertical load capacity. The nut includes anti-backlash preloading and asophisticated decoupling system that prevents lead screw eccentricity errorsfrom affecting stage movement. Specific Details: Travel Range 20 mm Minimum Incremental Motion, Linear 0.3Âµm Maximum Speed 20 mm/s Resolution 0.1Âµm Load Capacity 200 N On-Axis Accuracy 6Âµm Uni-directional Repeatability, Guaranteed 1Âµm Reversal Value (Hysteresis), Guaranteed 5Âµm Pitch 85Âµrad Yaw 50Âµrad Motor UE34PP, 1 Full step = 10Âµm Thread Type M4 and M6 Bearings Linear ball bearings Drive Mechanism Precision ground backlash-compensated leadscrew with decoupling nut Drive Screw Pitch 2 mm Limit Switches Optical Origin Optical, at center of travel Typical 5Âµm repeatability Drive Type Micro Stepper MTBF 20,000 hrs with 5 kg load and 30% duty cycle h Weight 2.9 kg Normal Load Capacity (Cz) 200 N Axial Load Capacity (+Cx) 50 N Axial Load Capacity, Inverse (-Cx) 10 N kax, Compliance in roll 10Âµrad/Nm kay, Compliance in pitch 15Âµrad/Nm kaz, Compliance in yaw 15Âµrad/Nm Off-Center Load Equation (Q) Q <= Cz / (1 + D/50) . Contact Us | Shipping | Payment | Item Description Contact Mailing Address: SurplusEQ 329 W. Melinda Ln. Phoenix AZ 85027 U.S.A. Phone: Toll-Free: (623) 581-9777 (877) 967-1904 Business Hours: 7:30am - 4:00pm (Arizona time) Monday to Friday Email: ebay@surpluseq.com View our other eBay Auctions and Feedback Profile. Payment We accept the following forms of payment: Credit/Debit Cards: Accepted for USA and Canadian eBay transactions pursuant to our eBay Sales Policy*. Cards accepted: Visa, MasterCard, Discover Card, and American Express. We may require shipping to the card holder's billing address and signed CC Authorization form. PayPal: Accepted for USA and Canadian transactions pursuant to our eBay Sales Policy*. Shipping to a PayPal verified address may be required. Authorization for PayPal acceptance when the item is being shipped to outside of the U.S.A. at our discretion. Contact us with questions. Sales Tax: Arizona (AZ) sales tax in the amount of 8.3% is collected unless buyer provides a valid AZ Sales Tax Exemption Certificate prior to payment. Shipping Use the shipping quote calculator supplied by eBay, or contact us for a shipping quote for freight items. Do not hesitate to contact us directly if you feel the shipping calculated using the eBay quote calculator is excessive. We generally do not ship on the buyer's shipping account, except in unusual circumstances. Contact us prior to bidding if you wish to use your account. Most items ship using UPS. USPS may be used upon request. Most items are shipping within one business day unless otherwise indicated. We will help you to find the lowest, reliable rates for any pallet or crate shipments, and you may use your own freight carrier with no additional costs except typically a palletizing charge. If an item appears to be damaged due to shipping, PLEASE SAVE ALL PACKAGING MATERIAL and contact customer service immediately. International We use UPS for international shipments. In some exceptional instances we may us USPS. If the eBay site's shipping quote calculator total seems excessive then we encourage you to contact us immedatly.. Box size of each item is specified in our database and some international shipping quotes can be reduced by finding a more accurate box size. Domestic We use UPS with most packages, or USPS for some small packages. All items shipped by UPS include insurance. Items exceeding 150lbs, or larger than UPS allows must be shipped by freight using a pallet or crate and must quoted manually. Contact us prior to bidding for freight shipping quotes. Local Pickup You are welcome to pick up your purchase during normal business hours M-F, 8am to 4pm.

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Micro Controle
Manufacturer	Klinger / Micro Controle
Model	Motorized Stages
Type of Control	Motorized
MPN	UE-71 PP
Axes of Travel	XY
