Micro Interface Circuit Board Charge Module Protection Board Lithium Battery

US $5.31

shanghai, China
Jul 23rd

Open on mobile:
QR code

Battery over discharge protection voltage: 2.5V Interface:Mini Interface;OR MICRO Interface Battery overcurrent protection current: 3A Board size: 2.6 * 1.7CM Maximum charge current: 1000mA Input voltage: 5V Package Include: 1PCS Charging cut-off voltage: 4.2V ± 1% Module features and parameters: Input with MINI USB female base, you can directly use the phone charger to do input to the lithium battery charge, And still retains the input voltage wiring pads, can be very convenient DIY Can be used for voltage 3.6 3.7V and so on 18650, polymer and other lithium battery charge and discharge protection, single or multiple parallel can also be used Module application range This module is used for single-cell lithium or multi-section parallel lithium charging, charging port can take power from the USB. Instructions for use / precautions 1. Test current ammeter can only be connected in series at the 5V input of the charging board. 2. Charging current is best battery capacity of 0.37C, is 0.37 times the capacity, such as 1000mAH battery charge current 400 is enough. Too fast to charge the effect of fast, red finished the battery voltage out on the more! 3. The charging connection wire can not be too long. So that the connection resistance is large. Too thin words out of the battery voltage out of the more. 4. Good connection with the battery is good. Or rushed out of the battery voltage out of the more. 5. If the 5V input voltage is high, such as 5.2 or even 5.5, will cause the charging current less than 1000mA, which is normal. High voltage chip heat will automatically reduce the charge current, not to burn the chip. Chip in the work of about 60 degrees heat isnormal. After all, the charging current is large. 6. Input reverse does not affect the chip, but the output (battery side) will burn back the chip, please note buyers.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
Manufacturer Part Number	Does not apply
MPN	Does not apply
Label	ATMA3B58/1075
Brand	Unbranded
