Microchip Mplab Real Ice, Dv244005 In-circuit Programmer Debugger Emuator

US $250.00

San Jose, California, United States
Jun 9th

Open on mobile:
QR code

Used, working. Product Description MPLAB REAL ICE In-Circuit Emulator System is Microchip’s next generation high speed emulator for Microchip Flash DSC® and MCU devices. It debugs and programs PIC® and dsPIC® Flash microcontrollers with the easy-to-use but powerful graphical user interface of the MPLAB Integrated Development Environment, included with each kit. The MPLAB REAL ICE probe is connected to the design engineer's PC using a high-speed USB 2.0 interface and is connected to the target with either a connector compatible with the popular MPLAB ICD 2 system (RJ11) or with the high speed, noise tolerant, low voltage differential signal interconnection. MPLAB REAL ICE is field upgradeable through future firmware downloads in MPLAB IDE. In upcoming releases of MPLAB IDE, advanced devices will be supported, and features added. The Standard Probe Driver uses a MPLAB ICD 2 type connector (RJ11) to connect to the target application. Designs that are compatible with MPLAB ICD 2 debugging/programming are quickly converted to the use of MPLAB REAL ICE. This driver board is included in the MPLAB REAL ICE Probe Kit (DV244005). Some 8-pin, 14-pin and 18-pin devices use small header boards with a special MCU for debugging. This special MCU has extra pins for MPLAB REAL ICE communication and therefore allows the use of all pins on the part for the application. The header board is not used or needed for programming. However, when debugging these devices the header must be used. Features: Low cost Full speed emulation Fast debugging and programming Ruggedized probe interface High speed connectivity (High Speed option) Long cable interconnects (validated to 3 meters) MPLAB IDE integration (included free) Small footprint (3 3/8”x4 5/8”x3/4”) Real-time execution and real time trace collection Stopwatch Real time watch Full hardware debugging: breakpoints, single-step, variable inspect/modify 8 Logic probe inputs/outputs I/O Port trace and SPI trace options for high speed upload of trace data Over voltage/short-circuit monitor protection Low voltage: to 2.0 volts (2.0V to 5.5V range) High speed USB 2.0 communication protocol

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	Microchip
MPN	DV244005
Model	Real-ICE
