Microchip Pic16f1939 Pic Mcu Development Board Icd3 Pickit2 Pickit3 Pickit Icd2

US $25

Bangkok, Thailand
Jun 14th

Open on mobile:
QR code

The PIC16F1939 MCU Development Board is a powerful solution for users looking to create new projects and applications. This board includes a microcontroller from Microchip's PIC family, specifically the PIC16F1939 40PIN MCU. It has the ability to operate at both 3.3V and 5V power supplies, providing flexibility for users depending on their goals. This mini board has the necessary circuits already built-in, making it an excellent choice for basic training and various applications. As a marketplace platform, the seller aims to provide US buyers an easier, faster, and more direct way to access quality products at attractive wholesale prices from selected standard manufacturer sellers. Customers can visit www.micro4you.com for more information or bulk ordering. The kit includes one PIC16F1939 Development Board and one CDROM (schematic and source code). Payment can be made through Paypal, which allows credit card, debit card, bank transfer, and Paypal account balance options. The board has the capability to adjust Signal I/O for multiple applications, providing users with added convenience and suitability. Additionally, it offers more devices for testing Input/Output on the internal board, allowing users to test operation while developing their programs. Shipping will be processed within 1-2 business days after payment is cleared. Packages will be delivered by Registered Air Mail, with most items reaching most countries within 8-15 working days. Delivery time depends on the destination and other factors, with some remote areas taking more than 20 working days. If the item is not received after 30 days, customers should contact the seller to investigate and solve the delivery problem. Other features include In-Circuit Programming with Microchip ICD2, ICD3, PICKIT2 and PICKIT3, 35 I/O points with easy-to-connect standard headers, USB V2.0 support and connection, two RS232 Connections (Hardware UART1, Software UART), 256Byte Internal EEPROM, 14 Channel 10-bit A/D Convertor, 1 Channel 16-bit Timer with 4 Channel 8-bit Timers, Power and Programming LED, Reset Button and Program-Run Switch, On-Board Regulator for 3.3V, Adjustable (VR1) for test Analog Input, Switch (SW1) for test Digital Input, LED (Green) for test Digital Output, and PCB Size 8 x 6 cm. Feedback is appreciated, with a Five Star Rating being encouraged for optimal customer
