Mieo Ct3 D16mm Wire Split-core Current Transformer Sensor For Ha102 & Ha104 Two/

US $1500

US, United States
Jun 18th

Open on mobile:
QR code

MIEO CT3 D16mm Wire Split-core Current Transformer Sensor for HA102 & HA104 Energy Monitor Single/ Two/ Three Phases D0.39inches/D10mm Clamp Sensor for Wireless Electricity Monitor 1)Primary Current (Arms50/60Hz): Max 70A 2)Secondary Current at primary nominal (rms): 20mA 3)D.C. Resistance at 25.C (Ohm): Max 460Ohm 4)Burden resistive load of secondary winding: 50 Ohm 5)Secondary output voltage at primary nominal for 15Ohm load: 500mv 6)Amplitude Error f(%) in the range of primary current from 1A to 60A: +-2% 7)Phase Angle Error in the range of primary current from 1A to 60A and at frequencies 50/60Hz: +-2.5C 8)Insulation between primary non-insulated wire,touching inside surface of the window,and secondary output must withstand AC rms voltage: 2500v/amA/3min 9)Temperature error of currents ratio: less than 50ppm/k 10)Insulation resistance (500VDC): 100MQ Min 11)Ambient operating temperature range: -40F to 176F 12)Suitable for the fire wire whose diameter less than D0.39inches/D10mm Three sensors will be required for 3-phase system. "Wireless Electricity Monitor" is an ideal digital monitor for checking electricity consumption,inspecting the wind or solar power generator and any power systems. It displays energy usage information in LCD screen with backlight. "Wireless Electricity Monitor"includes: Current Sensor:Just clamp on the fire wire to measure the current with electromagnetic induction. Transmitter: Transfer the data from Current Sensor to the Monitor with wireless signal. Monitor: Receives the real-time date from Transmitter and displays readable parameters such as electricity consumption,cost and historical consumption chart. - Primary Current (Arms 50/60Hz): Max 70A MIEO CT3 D16mm Wire Split-core Current Transformer Sensor for HA102 & HA104 Energy Monitor Single/ Two/ Three Phases Shipping All orders are usually shipped out within one to two business day. Your order will be shipped out via one of my participating partners, which include UPS, USPS, FedEx, DHL, among others. At this time, I only ship to physical addresses that are located within the 48 contiguous states of the United States of America. I am unable to ship to P.O. boxes, APO or FPO addresses, or international addresses. Tracking Once I have confirmed that your order was picked up by the shipping carrier, I will update the tracking information through eBay. Local Pick Up Unfortunately, due to the nature of my business, I do not offer local pick up. I want you to have all the benefits that eBay offers, in which eBay Buyer Protection is an important one. To ensure that you are qualified for eBay Buyer Protection, I only accept payment through Paypal. Paypal allows you to complete your purchase quickly and securely. It offers a wide variety of payment options, including all major credit cards, Paypal balance, Paypal Pay After Delivery, Paypal direct bank transfer and Paypal giftcard. To give my customers equal access to my inventory, I require immediate payment.
