Mini Atmel Avr Atmega Stk500 Usb Isp Programmer

US $290

shenzhen, China
Jan 29th

Open on mobile:
QR code

????? You are purchasing Mini ATMEL AVR ATMEGA STK500 USB Programmer ISP(RDB-DA11112) Read Notice Tips carefully under the pictures before you buy them. Upgrade shipping to TNT express or Regitstered Air Mail Service: For all bills with final value over $19.9, we will use registered air mail to ship them for free. Otherwise if your bill is less than 19.9 and you want registered airmail shipping, please add $2 when finishing payment. For all shipping to West and North Europe, USA, Canada, and Australia, we provide a $10 upgrade service to TNT express, no matter how many items you purchase or what the final weight is. Items will arrive in 3-5 working days and get much better care in the shipment. We strongly suggest our customer to choose this service. We provide a great discount in UPS and FEDEX service to USA and Canada too, contact us for more information. EU countries list: UK, Denmark, Finland, France, Greece, Ireland, Luxemburg, Germany, Italy, Netherland, Norway, Portugal, Spain, Swiss, Switzerland and Malta. Do not adjust the final amount when finishing payment if you are not going to upgrade your shipping. Picture Showcase Description Brief Introduction: Outline Dimension:56.6mm x 74.6mm x 28mm Net weigt:150g / 5.4oz Features: This USB STK500 programmer supports a wide range of ATMEL AVR microcontrollor.m It communicates with PC vai USB port, and it works with most of PC & notebook computers. It works with ATMEL AVR Studio 4.13. Devices Supported List AT90sXXXX ATtinyXX ATmegaXXXX AT90s2313 ATtiny11 ATmega103 ATmega325P AT90s2323 ATtiny12 ATmega128 ATmega3250 AT90s2343 ATtiny13 ATmega1280 ATmega3250P AT90s4414 ATtiny15 ATmega1281 ATmega329 AT90s4433 ATtiny22 ATmega16 ATmega329P AT90s4434 ATtiny2313 ATmega161 ATmega3290 AT90s8515 ATtiny24 ATmega162 ATmega3290P AT90s8535 ATtiny25 ATmega163 ATmega406 / ATtiny26 ATmega164P ATmega48 / ATtiny261 ATmega165 ATmega48P / ATtiny28 ATmega165P ATmega64 / ATtiny44 ATmega168 ATmega640 / ATtiny45 ATmega169 ATmega644 / ATtiny461 ATmega169P ATmega644P / ATtiny84 ATmega2560 ATmega6450 / ATtiny85 ATmega2561 / / ATtiny861 ATmega32 / / / ATmega323 / / / ATmega324P / / / ATmega325 / / / / / Notice: You should connect the programmer step by step as following. Connect AVR STK500 with target board, make sure connection is OK. Power on the target board. Join up the USB A-B cable with programmer to the computer. For programming, the four lines required from the AVR chip to the ISP adaptor (dongle) are: MOSI (Master out, slave in): Data being transmitted to the AVR being programmed is sent on this pin. MISO (Master in, slave out): Data received from the AVR being programmed is sent on this pin. SCK (shift clock): Serial clock generated by the programmer from the PC. RST (Reset ) : Reset(low pulse) generated by the programmer. NC: A black space. VTG: While release one port it will result in VTG on the appropriate port header connect. Valid target voltage range is 5 V. GND: Signal ground and power ground. Packing Include: 1X Mini ATMEL AVR ATMEGA STK500 USB Programmer ISP 1X USB Cable Documents: Go to Download Center for Manual, Driver and Tutorial. Keyword: DB-AD001 Shipping & Handling Payment Method Refund and Return On Jul-26-13 at 20:55:29 PDT, seller added the following information:
