Mini Pc-based Signal Function Arbitrary Waveform Generator 10mhz 3'' Tft Lcd Usb

US $97.00

Shenzhen, China
Mar 25th

Open on mobile:
QR code

Note: we'll ship this item via Epacket to US, usually the delivery time is about 3 weeks; for other countries, we'll ship it via registered air mail of Post, usually the delivery time is about 40-50 days. If you want express mail service, please contact us for extra postage in advance. Arbitrary Waveform Generator Gk101 10MHz Arbitrary Waveform Generator based on a number of advanced technology, achieves functions that common instrument has in a small volume. The palm-sized instrument achieves 80M sampling rate, 10MHz maximum frequency, 10Vpp highest amplitude. The instrument has a full-featured management of arbitrary waveform output function. Arbitrary waveform data use file system management, the protocol is open to users .Users can easily manage multiple arbitrary waveform files through virtual U disk technology. The instrument uses a high-resolution 3-inch color LCD with a resistive touch screen. With very expressive English language interface, users can quickly use it to express waveform parameters perfectly. The instrument has a firmware upgrade function. GINGKO will gradually upgrade the instrument firmware based on user feedback . 1. Technical Indicators #Waveform Characteristics Standard Waveforms: Sine SINC DC Square Noise Gaussian Triangle Exponential rise Negative half-wave Sawtooth rise Exponential fall Positive half -wave Sawtooth fall Positive full-wave Negative full-wave Sample Rate: 80MS / s Vertical Resolution: 14bit Arbitrary Waveform Length: 2 ~ 32K points Built-in Storage: 128M # Frequency Characteristics Output Range: Sine: 1mHz ~ 10MHz Square : 1mHz ~ 10MHz Others: 1mHz ~ 10MHz Resolution: 1mHz Accuracy: 50ppm # Voltage Characteristics Output Range: 10mVpp ~ 10Vpp Resolution: 12bit Accuracy: 8% of setpoint Offset Range: 5V Amplitude Flatness: $ 0.3dB # Square Characteristics Duty Cycle : 1mHz ~ 1MHz: 0.1% ~ 99.9% 1MHz ~ 10MHz: lock 50% Rise / Fall Time: <20ns Overshoot: <5% # General Output Impedance: 50 ? Ramp Symmetry: 0.1% ~ 99.9% Sync Signal: 4.8V ~ 5.2V, TTL level Power Requirements: DC 4.75V ~ 5.25V, <400mA Display Characteristics: 3-inch, 240x400 resolution Dimensions (L x W x H): 116mmx76mmx26mm Weight: 180g Accessories: a stylus, a Q9 probe, a USB cable, a power adapter

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	GK101
Country/Region of Manufacture	China
MPN	GK101
