Mirtec Mv-7l In Line Type Vision Inspector Aoi Vision Inspection System ; 2006

US $36,000.00

Orlando, Florida, United States
Jan 30th

Open on mobile:
QR code

Mirtec MV-7L In Line Type Vision Inspector AOI 45mm Topside Clearance option NG Marking system Installed 2007 2006 Vintage Serial # 17060309-0055 208V-240V Single Phase 15A 50-60 Hz MV-7L is a vision inspection system, which inspects the defects of the component, which is mounted. It uses the CCD COLOR camera and image management techniques to test the error in position of the mounted components. It prints out the test results on the monitor screen, thus the user can easily repair the errors. Also, it statistically calculates the test result data to share the results by other system and network. Machine dimensions: 52" deep (plus monitor/keyboard stand) x 67" wide (including rails) x 54" tall Weight: 900 kg (About 2000 lbs.) Conveyor Constitution: 3 Section (standby, inspection, extraction) 3 Step conveyor Heights: 900 mm +- 30 mm Width: Max: 450 mm / Min. 50 mm Width control: Automatic width adjustment PCB Fixing: Stick panel fast to Base Rail with 'Side Pusher' and 'PCB fixing Cylinder' PCB Size: 50 x 50 mm - 500 x 400 mm (2.5" x 2.5" - 19.7" x 15.7") Optical Camera: 1280 x 960 Pixel High Definition Digital Camera Light: 3 Layers (Horizontal, Vertical, Coaxial) Round type high brightness white color LED is mounted (256 level brightmess control) FOV: 20.5 x 15.5 mm (0.81" x 0.61"), 16.0 um/pixel 12.5 x 9.4 mm (10.49 x 0.37"), 9.8 um/pixel Inspection Objectives: Standard angled chip: From 0603 size LSI Part: From 0.4 Pitch Inspection Item: Mounting: Missing, Miss-align, Manhattan, Polarity, Damage Soldering: Void, Insufficient, Between Leads/Parts Solder touch Inspection time: Dimension per sec. = 20.5 mm x 15.5 mm x 3.85 Frame/sec = 1223.3 mm/sec Frame per sec. = 0.26 sec/frame Defect data process: Display the defect position on monitor Marking on defect position using NG marker NG Marking: 1 sec./ Marking point PCB Loading: Less 5 sec. (Loading + Unloading) Fiducial Mark Finding: 1 sec./2 Points Includes Manuals Buyer is responsible for shipping Shipping: We can build custom pallets and crates for an extra charge. International shipping is available on most items please ask before bidding. Returns: All items are sold as-is unless otherwise stated. Returns are not accepted unless item is defective or grossly misrepresented. Notify us of any issue within 7 days of receiving product. Feedback: Feedback is very important and we want happy customers. Please email or contact me with any concerns, issues or problems before leaving feedback and give me that opportunity to work things out if needed. Communication is key. We strive to provide a good product at a good price with fast shipping and great customer service. We realize that mistakes happen every now and then so please talk to us and we will make it right. Please checkout our other products at our ebay store. New items are added daily. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition

Used :

An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.

Seller Notes

“We do our best to accurately describe every item we sell. If the item is classified as used - the test performed are power up - dry cycle / zero testing. These machines are not refurbished unless specified in the listing and may need minor adjustments or repair. By doing the power up / zero testing we do verify that all of the major components(CPU/Servo Cards/Motors/IO Boards) are working and the machine is complete and functional. All of our items are available to be viewed prior to sale. If your requirement is for a reconditioned / refurbished machine please feel free to contact us - although the prices on those systems is higher - the machine will come in 100% production ready with warranty.”
