Miteq 70 Mhz Variable If Delay And Amplitude Slope Equalizer, Veq-2-70, Dual Ch

US $1,200.00

Rochester, Michigan, United States
Jan 29th

Open on mobile:
QR code

MITEQ VARIABLE IF EQUALIZER MODEL # VEQ-2-70 . . Item Description: This series of variable group delay and amplitude slope equalizers are designed to compensate for the nonlinear delay distortion and amplitude slope introduced by the various components and sub-systems of the satellite earth station. Specifications Frequency: 70 Mhz Number of channels: 2 Number of group delay sections: Eight (four group delay modules) Gain: 0 dB nominal, at center frequency Group delay adjustment range (70 ±18 MHz) Parabolic: 0.04 to 0.15 ns/MHz2 (per section) Linear: 0 to ±1.5 ns/MHz (per section) Group delay adjustment range (140 ±36 MHz) Parabolic: 0.006 to 0.019 ns/MHz2 (per section) Linear: 0 to ±0.37 ns/MHz (per section) Amplitude slope adjustment range: ±3 dB Input return loss: 23 dB minimum Output return loss: 20 dB minimum Input/output impedance: 75 ohms Amplitude flatness: ±0.1 dB maximum Power output (1 dB compression): +8 dBm minimum Third order output intercept point: +18 dBm IF output level fault adjustment range: 0 to -15 dBm (there is an internal switch Two power cords included Very Good Condition Manufacturers Specs: http://www.miteq.com/docs/D-107.PDF We will Consider all reasonable offers Payments must clear before items ship Buyer responsible for all shipping costs Questions are always welcome PLEASE NOTE, THE FDA DISCLAIMER BELOW IS FOR MEDICAL DEVICES/EQUIPMENT REQUIRING GOVERNMENT AUTHORIZATION: "The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, do not bid on this item unless you are an authorized purchaser. If the item is subject to FDA regulation, we will verify your status as an authorized purchaser of this item before shipping of the item." “If this unit has been used. It has been cleaned in accordance with the manufacturers guidelines by the medical facility from which we received it.” Return Policy If the item you purchased was misrepresented by us or damaged in shipping, you can obtain a full refund. To get a full refund, you must call or email us within 14 business days of receiving your item. Returns require our approval and return authorization and must be returned to us before we can issue your refund. Please note: we record serial numbers to discourage fraud. If you changed your mind and do not want your item, we can authorize you to return it for a refund of the cost of the item, not including shipping. We will not accept returns in cases when the condition of the item and/or retail packaging has been compromised, changed, modified or altered. The buyer is responsible for return shipping and is required to complete a "Mutual Agreement to Cancel the Transaction Form" through eBay. Guedes Electronics Inc. Rochester MI 248-805-1167

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	MITEQ
MPN	VEQ-2-70
Model	VARIABLE IF EQUALIZER
