Mitutoyo 178-561-11a Surftest Sj-210 Surface Roughness Tester, 0.75mn

US $2,721.60

Wilmington, North Carolina, United States
Jul 19th

Open on mobile:
QR code

Mitutoyo 178-561-11A Surftest SJ-210 Surface Roughness Tester, 0.75mN Model: SJ-210 | Order No:178-561-11A Handheld surface roughness tester with a 2.4-inch, backlit, color, LCD touch screen that displays sectional calculation results and assessed profiles, load curves, and amplitude distribution curves and has a micro-SD card that stores up to 10,000 results. Brand: Mitutoyo Model: SJ-210 Order No: 178-561-11A Condition: NEW Description Mitutoyo 178-561-11A Surftest SJ-210 Surface Roughness Tester, 0.75mN Mitutoyo 178-561-01A Offers This surface tester has an Ingress-Protection (IP)-53 rating for water and dust resistance. It displays total and sectional measurement results, assessed profiles, evaluation curve, bearing area curve (BAC), amplitude distribution curve (ADC), and waveform results. Profile images can be zoomed up or down. The Surftest can display results in sixteen languages. An integrated micro-SD card stores 10,000 measurement results, and supports screen capture. A built-in battery allows for approximately 1,000 measurements with four hours of charging time. The unit's memory stores up to 10 measurement conditions, and one measured profile. Operational keys on the front of the unit and under the sliding cover are labeled, and display settings have left and right arrow keys. Keys are displayed on the front of the unit, and additional, less frequently used keys are hidden under the sliding cover to prevent unintended operations. The unit has a stylus alarm that indicates when cumulative measurement distance exceeds the preset limit. The detachable drive unit can be separated from the display unit with a cable for maneuverability. The SJ-210 has auto-calibration that can be initiated with numerical value entry, and gain adjustment for color clarity. An auto-sleep function can be activated to automatically turn the power off, if there has been no operation for 10 to 600 seconds. Measurement conditions are saved when power is turned off. The unit has parameter customization for calculation and display. It has a "go/no-go" (G/NG) parameter judgment with maximum value of 16% rule option, and ANSI standard deviation selection option. Features Portable, handheld device used to measure surface roughness in shop, metalworking, manufacturing, and quality control (QC) applications 2.4-inch, color, backlit, LCD touchscreen displays in vertical or horizontal orientation, left- or right-hand views, and has an Ingress-Protection (IP)-53 rating for water and dust resistance Auto-calibration for accurate measurement of 39 parameters, five profiles, and storage of up to 10 measurement conditions, and one measured profile Displays total and sectional measurement, and evaluation curve, bearing area curve (BAC), amplitude distribution curve (ADC), and waveform results Micro-SD card stores up to 10,000 results with data in 16 languages, and supports screen capture Applications Manufacturing Machining Metal working Quality control Included What's included with the Mitutoyo 178-561-01A 178-561-01A SJ-210 Surftest Surface Roughness Tester 12BAA303 Connecting Cable 178-602 Roughness Specimen (Ra 3.00µm) 12BAK699 Carrying Case 12BAK700 Calibration Stage 12BAK820 Protective Sheets for Display AC Adapter Operation Manual Quick Reference Manual Warranty Specifications Mitutoyo 178-561-01A Specifications Measuring Range 14200 µin (-7900µin~+6300µin) / 360µm (-200µm ~ +160µm) Measuring speed Measuring: 0.01, 0.02, 0.03 in/s (0.25mm/s, 0.5mm/s, 0.75mm/s) Returning: 1mm/s Measuring force / Stylus tip 0.75mN type: 0.75mN / 2µmR 60°, 4mN type: 4mN / 5µmR 90° Skid force Less than 400mN Applicable standards JIS '82 / JIS '94 / JIS '01 / ISO '97 / ANSI / VDA Assessed profiles Primary profile / Roughness profile / DF profile / Roughness profile-Motif Analysis graphs Bearing area curve / Amplitude distribution curve Filters Gaussian, 2CR75, PC75 LCD dimensions 1.45 x 1.93" (36.748.9 mm) Mass About 1.1lbs (00g) (Display unit + Drive unit + Standard detector Terms & Conditions Item Condition: Unless specified otherwise all products listed are Brand New in the original factory packaging and include a full factory warranty. Shipping: We currently only ship to U.S. buyers. We ship items within one or two business days from payment. We do not process shipments on weekends and holidays. Local pick up is not available. We only ship to addresses verifiable by either PayPal or credit card issuing bank. Please note that we cannot alter the address once a purchase is made. In the case of PayPal payment, we will ship orders when the payment is marked “Eligible” for PayPal Seller’s protection. *Shipping Rates are for Continental US, Please Contact us for other US Destinations Payment: Currently all payments must be made directly though PayPal Sales Tax: We are required to charge sales tax in North Carolina Return Policy: If for any reason you are not 100% satisfied with a product you receive from us, you may return the regular stock product within 30 days from the time of receipt, for a full refund or exchange of the product you purchased (less any shipping costs). Within this time, products may be returned; freight prepaid and must be in their original packaging and in resalable condition. Shipping errors, missing items or damages must be reported to us immediately (damages should be accompanied by a signed bill of lading acknowledging the damage). Items returned will be inspected for damage or misuse at which time they may be subject to restocking fees, other fees or refused, prior to the issuance of any credit.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Mitutoyo
MPN	SJ-210
