Mitutoyo - 543-280 Absolute Lcd Digimatic Indicator Id-c, M2.x0.45 Thread, 8mm

US $230

Brooklyn, New York, United States
Jun 9th

Open on mobile:
QR code

Mitutoyo - 543-280 Absolute LCD Digimatic Indicator ID-C, M2.X0.45 Thread, 8mm Accuracy: Refer to the list of specifications. Length standard: ABSOLUTE electrostatic capacitance type linear encoder. Max. response speed: Unlimited. Data output (-NG/OK/NG signal, NPN open collector), Remote control (hold-preset, preset-recall, zero-set), Origin-set/Preset, Zeroset, GO/+/-NG judgment, Max/Min/ Runout value holding, Counting direction switching, Power ON/OFF, inch/mm conversion (on inch/metric models only). Alarm: Low voltage, Counting value composition error, Over-flow error, Tolerance limit setting error. Measuring force: 2.0N or less. Product Features: With the max./min. Value holding function, the signal id-c can output the signal of the GO/+/-NG judgment result against the peak values set The signal can be output to an external device like a sequencer through the npn open-collector The go/+/-ng judgment result is also indicated by the green/red led and the "" signs on led Employing the absolute linear encoder, the signal id-c always displays the spindle "absolute position" from the origin at power-on The signal id-c achieves the ip54 protection level to resist dust and contaminants for safe operation in harsh machine shop environments, stem diameter 8mm, M2.-0.45 thread size Dimensions (in): 3.10 X 6.20 X 6.10 Important Information: We offer discounted rates for bulk purchases, please inquire. We combine shipping, please note that certain items cannot be combined. In case you don&rsquot see the shipping rate displayed, please feel free to contact us for a shipping quote. _________________________________________________________________ International Shipping: Ø if you need a super fast international shipping please contact us Ø We do combine shipping, the more you buy the lower the shipping cost. Ø International shipping may be subject to a longer handling time. Ø Estimated time in transit is still just an estimate, in some cases items are subject to an extended time in transit due to custom delays, extended inspections in your country or lack of efficiency of the postal service. Ø USPS Standard mail or Priority mail are not guaranteed to be trackable, the service which is guaranteed to be trackable is USPS EXPRESS mail. Ø Most items are shipped with USPS. However, if you prefer a different shipping method, please notify us prior to purchase. Ø We cannot be responsible for time in transit, custom fees or for custom delays. Ø All international items are insured. Thank you for Looking!
