Mitutoyo 543-558a Absolute Digital Indicator Id-f, 0-2" (0-50.8mm), Spc Output

US $891.52

Wilmington, North Carolina, United States
Jul 27th

Open on mobile:
QR code

Mitutoyo 543-558A Absolute Digital Indicator ID-F, 0-2" (0-50.8mm), SPC Output Model: ID-F150HE | Order No:543-558A Mitutoyo 543-558A ABSOLUTE Digimatic Indicator ID-F with Back-lit LCD Screen: 2"/50.8mm Range with 3-8" stem diameter and .00005", .0001", .0005", .001"/ 0.001mm, 0.01mm Resolution. Brand: Mitutoyo Model: ID-F150HE Order No: 543-558A Condition: NEW Description Mitutoyo 543-558A Absolute Digital Indicator ID-F, 0-2" (0-50.8mm), SPC Output Mitutoyo 543-558A Absolute Digimatic Indicators ID-F Series with Back Lit LCD Screen Features: With the Absolute Linear Encoder Technology, once the measurement reference point has been preset it will not be lost when the power is turned on GO/+_NG judgement is performed by setting the upper and lower tolerances. If a judgement result is out of tolerance, the display backlighting changes from green to red, so tolerance judgment can be made at a glance. An analog bar indicator has been integrated to handle upper/lower limit approaching and zero approaching. It enhances the ease of operation in the same manner as a dial indicator. The display range of the analog bar can be changed With SPC data output Measuring Range: 0-2in 0-50.8mm LCD Resolution: .00005/.0005/.0001/.001in 0.001/.01mm Accuracy (20 °C): plus or minus .00012in .003mm Measuring Force: 0-2.3N Stem Diameter: 3/8" 0.3754mm Contact Point: .16in (DIA) Steel Ball (4-48UNF) 900032 Power Supply: AC Adapter Data Output: SPC Digimatic output Included MLH-522 Mu-Checker Pivot Bearing Lever Head Probe 2m Cable 1mm Carbide-Tipped Stylus (520940) 2mm Stylus (520939) 3mm Stylus (520938) Specifications Measuring Range 0 to 2" (0 to 50.8mm) LCD Resolution 0.00005/0.0005/0.0001/0.001" (0.001/0.01mm) Accuracy (20°C) ±0.00012" (0.003mm) Max. Response Speed Unlimited Display LCD Power Supply 9V DC (via AC Adapter) Terms & Conditions Item Condition: Unless specified otherwise all products listed are Brand New in the original factory packaging and include a full factory warranty. Shipping: We currently only ship to U.S. buyers. We ship items within one or two business days from payment. We do not process shipments on weekends and holidays. Local pick up is not available. We only ship to addresses verifiable by either PayPal or credit card issuing bank. Please note that we cannot alter the address once a purchase is made. In the case of PayPal payment, we will ship orders when the payment is marked “Eligible” for PayPal Seller’s protection. *Shipping Rates are for Continental US, Please Contact us for other US Destinations Payment: Currently all payments must be made directly though PayPal Sales Tax: We are required to charge sales tax in North Carolina Return Policy: If for any reason you are not 100% satisfied with a product you receive from us, you may return the regular stock product within 30 days from the time of receipt, for a full refund or exchange of the product you purchased (less any shipping costs). Within this time, products may be returned; freight prepaid and must be in their original packaging and in resalable condition. Shipping errors, missing items or damages must be reported to us immediately (damages should be accompanied by a signed bill of lading acknowledging the damage). Items returned will be inspected for damage or misuse at which time they may be subject to restocking fees, other fees or refused, prior to the issuance of any credit.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Mitutoyo
MPN	ID-F150HE
UPC	603908260981
