Mj15022/mj15023 + (bonus)factory Matched, Recovered And Tested On Tektronix 576

US $260

Rainier, Oregon, United States
Aug 19th

Open on mobile:
QR code

SET OF 2 x MJ15022 / 2 x MJ15023 FREE 1 x MJE243 / 1 x MJE253 DRIVER TRANSISTORS WITH TD5 MICROSWITCH RECOVERED FROM OBSOLETE SPARE BOARDS FOR INVENTORY USED ON HIGH TEST ANALOG EQUIPMENT, OTHERWISE FULLY FUNCTIONAL.THIS COMPONENTS ARE FACTORY MATCHED. TESTED ON TEKTRONIX 576 CURVE TRACER BEFORE SHIPPING. BELOW LIST OF PARAMETERS FOR ALL OF THEM. MJE243 Datasheet, Equivalent, Cross Reference Search Type Designator: MJE243 Material of Transistor: Si Polarity: NPN Maximum Collector Power Dissipation (Pc): 15 W Maximum Collector-Base Voltage |Vcb|: 100 V Maximum Collector-Emitter Voltage |Vce|: 100 V Maximum Emitter-Base Voltage |Veb|: 7 V Maximum Collector Current |Ic max|: 4 A Max. Operating Junction Temperature (Tj): 150 °C Transition Frequency (ft): 40 MHz Collector Capacitance (Cc): 50 pF Forward Current Transfer Ratio (hFE), MIN: 40 Noise Figure, dB: - Package: TO126 MJE253 Datasheet, Equivalent, Cross Reference Search Type Designator: MJE253 Material of Transistor: Si Polarity: PNP Maximum Collector Power Dissipation (Pc): 15 W Maximum Collector-Base Voltage |Vcb|: 100 V Maximum Collector-Emitter Voltage |Vce|: 100 V Maximum Emitter-Base Voltage |Veb|: 7 V Maximum Collector Current |Ic max|: 4 A Max. Operating Junction Temperature (Tj): 150 °C Transition Frequency (ft): 40 MHz Collector Capacitance (Cc): 70 pF Forward Current Transfer Ratio (hFE), MIN: 40 Noise Figure, dB: - Package: TO126 MJ15022 Datasheet, Equivalent, Cross Reference Search Type Designator: MJ15022 Material of Transistor: Si Polarity: NPN Maximum Collector Power Dissipation (Pc): 250 W Maximum Collector-Base Voltage |Vcb|: 350 V Maximum Collector-Emitter Voltage |Vce|: 200 V Maximum Emitter-Base Voltage |Veb|: 7 V Maximum Collector Current |Ic max|: 16 A Max. Operating Junction Temperature (Tj): 200 °C Transition Frequency (ft): 4 MHz Collector Capacitance (Cc): 500 pF Forward Current Transfer Ratio (hFE), MIN: 15 Noise Figure, dB: - Package: TO3 MJ15023 Datasheet, Equivalent, Cross Reference Search Type Designator: MJ15023 Material of Transistor: Si Polarity: PNP Maximum Collector Power Dissipation (Pc): 250 W Maximum Collector-Base Voltage |Vcb|: 350 V Maximum Collector-Emitter Voltage |Vce|: 200 V Maximum Emitter-Base Voltage |Veb|: 7 V Maximum Collector Current |Ic max|: 16 A Max. Operating Junction Temperature (Tj): 200 °C Transition Frequency (ft): 4 MHz Collector Capacitance (Cc): 500 pF Forward Current Transfer Ratio (hFE), MIN: 15 Noise Figure, dB: - Package: TO3

“PROFESSIONAL RECOVERED FROM OBSOLETE ANALOG TESTING EQUIPMENT, TESTED ON TEKTRONIX 576 CURVE TRACER, FACTORY MATCHED,”

Country/Region of Manufacture

United States

Collector-Emitter/Drain-Source Voltage

200

Custom Bundle

Power Dissipation

250

Mounting Style

Through-Hole

Continuous Collector/Drain Current

Type
