Mk-328 Transistor Tester Capacitor Esr Inductance Resistor Meter Lcr Npn Pnp Mos

US $430

Hongkong, Hong Kong
May 10th

Open on mobile:
QR code

If you need the Multi-function Test Jig, please click: Multi-function Test Jig For Transistor Tes... MK-328 Transistor Tester Capacitor ESR Inductance Resistor Meter LCR NPN PNP MOS Description: This meter is an intelligent semiconductor device analyzer, it can measure most of the diodes, bipolar transistors, Junction/MOS FETs and low power thyristors. It automatically identifies the type of devices and pinouts, measures the current gain HFE, gate theshhold and FET junction capacitance, a typical application is to pair two transistors or identify an unknown SMD device. The test clips can be connected any way round, the pinout can be identified and displayed on screen vs. test clip numbers. Beside the semiconductor device analyzer, this meter can also work as a RLC/ESR meter, the RLC/ESR accuracy may not be able to compete with the professional one, but it definitely meets the needs for most of the applications. A 9V battery (part number 6F22) is used for this meter, the typical working current is about 20mA, standby current is about 20nA. Dimension: 83x152x34mm Weight: 175 gram (no exclude battery) Special caution: Discharge the capacitors completely before you measure it, otherwise, it could damage your meter! Features: 1, Operates with ATmega328 microcontrollers. 2, Displaying the results to a 128x64 graphic LCD-Display. 3, One key operation with automatic power shutdown. 4, Shutdown current is only about 20nA. 5, Automatic detection of NPN and PNP bipolar transistors, N- and P-Channel MOSFETs, JFETs, diodes, double diodes, Thyristors and Triacs. 6, Automatic detection of pin layout of the detected part. 7, Measuring of current amplification factor and Base-Emitter threshold voltage of bipolar transistors. 8, Darlington transistors can be identified by the threshold voltage and high current amplification factor. 9, Detection of the protection diode of bipolar transistors and MOSFETs. 10, Measuring of the Gate threshold voltage and Gate capacity value of MOSFETs. 11, Up to two Resistors are measured and shown with symbols and values with up to four decimal digits in the right dimension. All symbols are surrounded by the probe numbers of the Tester (1-3). So Potentiometer can also be measured. If the Potentiometer is adjusted to one of its ends, the Tester cannot differ the middle pin and the end pin. 12, Resolution of resistor measurement is now up to 0.01 , values up to 50M are detected. 13, One capacitor can be detected and measured. It is shown with symbol and value with up to four decimal digits in the right dimension. The value can be from 25pF to 100mF. The resolution can be up to 1pF . 14, For capacitors with a capacity value above 0.18?F the Equivalent Serial Resistance (ESR) is measured with a resolution of 0.01 and is shown with two significant decimal digits. 15, For capacitors with a capacity value above 5000pF the voltage loss after a load pulse can be determined. The voltage loss give a hint for the quality factor of the capacitor. 16, Up to two diodes are shown with symbol or symbol in correct order. Additionally the flux voltages are shown. 17, LED is detected as diode, the flux voltage is much higher than normal. Two-in-one LEDs are also detected as two diodes. 18, Zener-Diodes can be detected, if reverse break down Voltage is below 4.5V. These are shown as two diodes, you can identify this part only by the voltages. The outer probe numbers, which surround the diode symbols, are identical in this case. You can identify the real Anode of the diode only by the one with break down (threshold) Voltage nearby 700mV! 19, If more than 3 diode type parts are detected, the number of founded diodes is shown additionally to the fail message. This can only happen, if Diodes are attached to all three probes and at least one is a Z-Diode. In this case you should only connect two probes and start measurement again, one after the other. 20, Measurement of the capacity value of a single diode in reverse direction. Bipolar Transistors can also be analysed, if you connect the Base and only one of Collector or Emitter. 21, Only one measurement is needed to find out the connections of a bridge rectifier. 22, Capacitors with value below 25pF are usually not detectet, but can be measured together with a parallel diode or a parallel capacitor with at least 25pF. In this case you must subtract the capacity value of the parallel connected part. 23, For resistors below 2100 also the measurement of inductance will be done, if your ATmega has at least 16K flash memory. The range will be from about 0.01mH to more than 20H, but the accuracy is not good. The measurement result is only shown with a single component connected. 24, Testing time is about two seconds, only capacity or inductance measurement can cause longer period. 25, Software can be configured to enable series of measurements before power will be shut down. 26, Selectable facility to calibrate the internal port resistance of port output and the zero offset of capacity measurement with the selftest . A external capacitor with a value between 100nF and 20?F connected to pin 1 and pin 3 is necessary to compensate the offset voltage of the analog comparator. This can reduce measurement errors of capacitors of up to 40?F. With the same capacitor a correction voltage to the internal reference voltage is found to adjust the gain for ADC measuring with the internal reference. 27, Display the Collector cutoff current ICE0 with currentless base (10?A units) and Collector residual current ICES with base hold to emitter level . This values are only shown, if they are not zero (especially for Germanium transistors). 28, Thyristors and Triacs can only be detected, if the test current is above the holding current. Some Thyristors and Triacs need as higher gate trigger current, than this Tester can deliver. The available testing current is only about 6mA! Attention: Allways be shure to discharge capacitors before connecting them to the Tester! The Tester may be damaged before you have switched it on. There is only a little protection at the ATmega ports. Extra causion is required if you try to test components mounted in a circuit. In either case the equipment should be disconnected from power source and you should be shure, that no residual voltage remains in the equipment. Package Contents: 1pcs x MK-328 Transistor Tester Capacitor ESR Inductance Resistor Meter 3pcs x Test Clips (not included Multi-function Test Jig as show in second main picture) (if you need english User Guide, we can send it by mail) About Payment We accept PayPal only, all major credit cards are accepted through secure payment processor PayPal. Payment must be received in 7 business days of auction closing. Please leave note for your special request (e.g. Colors or Size) in ebay when you pay the order. Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched. About Shipping Item will be shipped within one business day after full payment is received. Except The United States and Russia we shipped use Epack, We ship worldwide with standard shipping by Hong Kong Air mail. This international order may take longer to arrive, Normally the shipment to worldwide is used to take 35 to 40 business days, exclude Sat & Sun.. Delivery time depends on destination and other factors, if you still not received it in normal days. Please don’t worry, I hope you can give me a message before you do any action. About Returns If the item is defect when you receive it or you are not satisfied with it, please return it within 14 days for a replacement or money back. But the items must be back in factory condition. Please contact us and double check the return address before you return it. Original and return shipping fee will not be refunded or reimbursed under all circumstances. You must agree and acknowledge this term if you bid for this item. Therefore, please do not complain about having to ship back at your own expense. Any feedback. We are committed to resolve all issues in a friendly and satisfactory manner. We always reply to ebay messages within 1-2 business days. If you do not get a response from us, then please check your ebay message. we only reply by ebay message, no send email. About Feedback Dear buyers, we appreciate your business, if you are satisfied with our service, please leave me a postive rate, Your recognition will make us more confident to develop business and serve you better. Our goal is to make sure you are a happy buyer and pleasant shopping with us. Please give us ebay message before leaving any 1 or 2 ratings, neutral, negative feedback or open any dispute. We understand the concerns and frustrations you might have, and will do our endeavor to resolve the issues. Please give us the opportunity to resolve any problem. thank you very much! And hope to see you soon. Contact Us If you have any questions, please feel free to email our service specialists 24 Hours a Day, and we will reply you ASAP. If no response within 24 Hours, please check the spam of mail box or kindly re-send it to us. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative or neutral feedback without any contact. If you haven't received item in 30 days, please contact us and we will arrange refund or resend.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	MK-328 TR\LCR\ESR Transistor \LCR\ESR Tester
Country/Region of Manufacture	China
