Mk328 Lcr Esr Tester Transistor Inductance Capacitance Resistance Meter Portable

US $2500

Los Angeles, California, United States
May 27th

Open on mobile:
QR code

Portable MK-328 LCD Transistor Tester Diode Capacitance LCR ESR Meter YC QS41 Item Description: Portable MK-328 LCD Transistor Tester Diode Capacitance LCR ESR Meter YC QS41 Description: Multi-functional transistor tester for automatic detection of NPN and PNP transistors, N-channel and P-channel MOSFETs, JFETs, diodes, double diodes, Thyristors and Triacs. Features: - Operates with ATmega328 microcontrollers. - Digital LCD backlight display for easy readings, can display measured data and graphics. - One key operation with automatic power shutdown. - Can be powered by 9V battery(not included). - With shell and bracket, portable and convenient for use. - Automatic detection of NPN and PNP bipolar transistors, N-Channel and P-Channel MOSFETs, JFETs, diodes, double diodes, Thyristors and Triacs. - Automatic detection of pin layout of the detected part. - Measure of current amplification factor and base-emitter threshold voltage of bipolar transistors. - Detection of the protection diode of bipolar transistors and MOSFETs. - Measuring of the Gate threshold voltage and Gate capacity value of MOSFETs. - Resistance measurement resolution is 0.1 ohms, 50M ohms can be measured. - Up to two diodes are shown with symbol or symbol in correct order. Notice: Before measuring capacitance, the capacitor must be discharged, otherwise very likely damage the meter. Specifications: - Display: 128*64 LCD Backlight - Input Voltage: 9V - Current: Approx. 20mA - Power Supply: 1 * 9V Battery(NOT Included) - Resistance Measurement: Max. 50MΩ - Resistance Resolution: 0.1Ω - Capacitance Measurement: 25pF~100mF - Capacitance Resolution: 1pF - Inductance Measurement: 0.01mH-20H - Screen Size: 5 * 2.7cm / 1.97 * 1.06in - Product Size: 15 * 8 * 3.5cm / 5.9 * 3.15 * 1.4in - Product Weight: 188g / 6.65oz - Package Size: Approx. 17 * 10 * 3.5cm / 6.7 * 3.94 * 1.4in - Package Weight: 215g / 7.58oz - Backlight Color:Green/White( at random) Package included: - 1 * E1164 - 1 * Transistor Tester - 3 * Test Cable Shipping&payment: Here Offer 100% Satifiation Service,Inlucde re-send item&refund payment; All items here offer 1 year warranty It is not my Duty for Custom Tax All items will be shipped via int'l air mail(( no tracking number for items under $65), the time normally takes 7-15 business days. may be later arrivel if the item is checked by custom; We only accept paypal payment.
