Mks Baratron 225ad-00001aab Differential Capacitance Manometer, New

US $199.00

Utica, Michigan, United States
Jan 29th

Open on mobile:
QR code

225AD-0001AAB Baratron Differential Capacitance Manometer Range: 1 Torr Input: +11-30 VDC Output: 0-5 VDC Brand new in factory packaging, never used -- From manufacturer's website: Specifications 225A Baratron® Differential Capacitance Manometer 225A Baratron® Full Scale Ranges Standard 0.2, 1, 10, 100, 1000 mmHg Optional 0.2, 1, 10, 100, 1000 cmH20 0.1, 0.25, 0.5, 5, 50, 500 inH20 (for 0.25 inH20 Full Scale range, consult Applications Engineering for ordering code) Resolution 0.01% of Full Scale Accuracy Standard ±0.5% of Full Scale, bidirectional or unidirectional Optional ±0.3% of Full Scale, bidirectional or unidirectional ±0.3% of Reading, unidirectional only Temperature Coefficients Zero 0.1% of Full Scale/°C Span 0.04% of Reading/°C Ambient Operating Temperature 0° to 50°C Maximum Overpressure 120% of Full Scale or 20 psi (140 kPa), whichever is greater For Full Scale ranges less than 1000 mmHg, the following restrictions apply: if high pressure is on the Measurement (Px) side of the sensor, the maximum differential overpressure allowable is 120% of Full Scale or 20 psi, whichever is greater; if high pressure is on the Reference (Pr) side of the sensor, the maximum differential overpressure allowable is 120% of Full Scale. Consult Applications Engineering for higher Reference (Pr) overpressure protection. Maximum Line Pressure 40 psig (275 kPa) Materials Exposed to Gases Measurement (Px) side Inconel® Reference (Pr) side Inconel, Ceramic, Palladium, Stainless Steel, Glass Volume Measurement (Px) side 1.3 cc Reference (Pr) side 9.8 cc Fittings 3/16 inch (4.6 mm) tubulation (consult factory if other fittings are required) Power Required ±11 to +30 VDC @ 25 mA, ripple <0.5 Volt peak to peak Output 0 to 5 VDC, unidirectional; 0 to ±5 VDC, bidirectional; into >10K or load (other ranges or outputs available by special order; Applications Engineering) Electrical Connector Screw terminal barrier strip Specifications are subject to change without notice. VCR® is a registered trademark of Swagelok® Company. Copyright MKS Instruments, Inc. unless noted otherwise. Unisolar Uni-solar

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	225AD
Brand	MKS
